FESTO ISO Cylinder Pneumatic Air Cylinders DSNU-25-15-P-A 1908305
Price:
EXW USD40-50
MOQ:
1pc
Delivery Time:
7-10 working days
Brand:
FESTO
Product Description
FESTO ISO cylinder DSNU-25-15-P-A 1908305 Pneumatic Air Cylinders
About product
Extensive range of accessories makes it possible to install the cylinder virtually anywhere
Cylinder barrel made of stainless steel
Bearing and end caps made of wrought aluminium alloy
Color:Silver
Cleanroom class:Class 6 according to ISO 14644-1
Technical Data
| Stroke | 15 mm |
| Piston diameter | 25 mm |
| Piston rod thread | M10x1.25 |
| Cushioning | Elastic cushioning rings/plates at both ends |
| Piston-rod end | Male thread |
| Design | Piston Piston rod Cylinder barrel |
| Symbol | 00991217 |
| Mode of operation | Double-acting |
| Corrosion resistance class CRC | 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Cleanroom class | Class 6 according to ISO 14644-1 |
| Ambient temperature | -20°C-80°C |
| Basic weight for 0 mm stroke | 238 g |
| Additional weight per 10 mm stroke | 11 g |
| Pneumatic connection | G1/8 |
| Note on materials | RoHS-compliant |
| Material seals | NBR TPE-U(PU) |
| Material piston rod | High-alloy stainless steel |
| Material cylinder barrel | High-alloy stainless steel |
There are so many models ,please contact with me.
General technical data
