FESTO 156881 Compact Pneumatic Air Cylinders ADVUL-32-50-P-A

Price Negotiable

Price: EXW USD50-80

MOQ: 1pc

Delivery Time: 7-12working days

Brand: FESTO

Product Description

FESTO Compact cylinder ADVUL-32-50-P-A 156881 Pneumatic Air Cylinders

About product

Stroke:50 mm

Piston diameter:32mm

Mode of operation:Double-acting

Technical Data

Stroke	50mm
Piston diameter	32 mm
Cushioning	Elastic cushioning rings/plates at both ends
Mounting position	optional
Design	Piston Piston rod
Position detection	Via proximity switch
Symbol	00991737
Variants	Piston rod at one end
Protection against torque/guide	Guide rod with yoke
Mode of operation	Double-acting
Corrosion resistance class CRC	2 - Moderate corrosion stress
LABS (PWIS) conformity	VDMA24364-B1/B2-L
Ambient temperature	-20°C-80°C
Pneumatic connection	G1/8
Material collar screws	Galvanised steel
Material cover	Wrought aluminium alloy
Material dynamic seals	NBR TPE-U(PU)
Material piston rod	High-alloy stainless steel
Material cylinder barrel	Wrought aluminium alloy

Data sheet

Delivery
1. If the products we have in store, we will send it out ASAP after payment.
2. If the products which were customized, we will complete the production within a specified period of time, and send it out the first time, we can promise it.
3. Also we can send by your delivery acount if you want.
4. We have a variety of ways to send goods, usually DHL, Fedex, TNT will be normal ways. If you require use of a courier, we can do it.

There are so many kinds. Please contact with me!
