170845 Guided Drive Pneumatic Air Cylinders FESTODFM-20-80-P-A-GF
Price:
EXW USD60-80
MOQ:
1pc
Delivery Time:
10-12working days
Brand:
FESTO
Product Description
FESTO Guided drive DFM-20-80-P-A-GF 170845 Pneumatic Air Cylinders
About product
Good protection against torsion
High rigidity
Maintenance-free
Guide:Plain-bearing guide
Corrosion resistance class CRC:1 - Low corrosion stress
Technical Data
| Stroke | 80mm |
| Piston diameter | 20 mm |
| Operating mode, drive unit | Yoke |
| Cushioning | Elastic cushioning rings/plates at both ends |
| Mounting position | optional |
| Guide | Plain-bearing guide |
| Design | Guidance |
| Position detection | Via proximity switch |
| Symbol | 00991737 |
| Mode of operation | Double-acting |
| Corrosion resistance class CRC | 1 - Low corrosion stress |
| LABS (PWIS) conformit | yVDMA24364-B1/B2-L |
| Ambient temperature | -20°C-80°C |
| Product weight | 1422 g |
| Pneumatic connection | M5 |
| Note on materials | RoHS-compliant |
| Material cover | Wrought aluminium alloy |
| Material seals | NBR |
| Material housing | Wrought aluminium alloy |
| Material piston rod | High-alloy stainless steel |
Characteristics
There are so many kinds. Please contact with me!
