Festo Push-In Y-Connector NPQH-Y-Q10-E-P10 578412 Pneumatic Tube Fittings
Price:
EXW USD3-5
MOQ:
1 PCS
Delivery Time:
10-12 working days
Brand:
FESTO
Product Description
Festo Push-in Y-connector NPQH-Y-Q10-E-P10 578412 Pneumatic Tube Fittings
About product
Design:Y-shape
Design:Push-pull principle
Note on operating and pilot medium:Lubricated operation possible
Pneumatic connection, port 1:For tubing outer diameter of 10 mm
Pneumatic connection, port 2:For tubing outer diameter of 10 mm
Technical Data
| Size | Standard |
| Nominal size | 9.5 mm |
| Tubing insertion depth | 18.3 mm |
| Mounting position | optional |
| Design | Y-shape |
| Size of pack | 10 |
| Design | Push-pull principle |
| Symbol00997424 | 00997424 |
| Certificate issuing authority | NSF C0523185 |
| Note on operating and pilot medium | Lubricated operation possible |
| Corrosion resistance class CRC | 3 - high corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Cleanroom class | Class 4 according to ISO 14644-1 |
| Ambient temperature | 0°C-150°C |
| Product weight | 65.9 g |
| Pneumatic connection, port 1 | For tubing outer diameter of 10 mm |
| Pneumatic connection, port 2 | For tubing outside diameter of 10 mm |
| Note on materials | RoHS-compliant |
| Material housing | Brass, chemically nickel-plated |
| Guard ring material | PEI |
| Material release ring | Brass, chemically nickel-plated |
| Material tubing seal | FPM |
| Material tubing clamp component | High-alloy stainless steel |
| Thrust ring material | PEI |
Materials
Attention
1.Before you endorse the parcel, please do open the package, and check out whether the items are damaged during the shipping process.
If so, please do refuse to sign for the parcel, the courier will send back the package to our company. Otherwise we are not responsible for this...
2.Any order is welcome. we will give discounts and combined shipping costs for you if you order more or mix order. If you have any questions.
please feel free to contact us.
Delivery
1. If the products we have in store, we will send it out ASAP after payment.
2. If the products which were customized, we will complete the production within a specified period of time, and send it out the first time, we can promise it.
3. Also we can send by your delivery acount if you want.
4. We have a variety of ways to send goods, usually DHL, Fedex, TNT will be normal ways. If you require use of a courier, we can do it.
There are so many models.Welcome to contact with me !
