FESTO Compact cylinder ADVUL-50-60-P-A 156901 Pneumatic Air Cylinders
Price:
EXW USD100-120
MOQ:
1pc
Delivery Time:
7-10 working days
Brand:
FESTO
Product Description
FESTO Compact cylinder ADVUL-50-60-P-A 156901 Pneumatic Air Cylinders
About product
Stroke:60 mm
Piston diameter:50 mm
Cushioning:Elastic cushioning rings/plates at both ends
Mode of operation:Double-acting
Ambient temperature: -20°C-80°C
Technical Data
| Stroke | 60 mm |
| Piston diameter | 50 mm |
| Cushioning | Elastic cushioning rings/plates at both ends |
| Mounting position | optional |
| Design | Piston Piston rod |
| Position detection | Via proximity switch |
| Symbol | 00991737 |
| Variants | Piston rod at one end |
| Protection against torque/guide | Guide rod with yoke |
| Mode of operation | Double-acting |
| Corrosion resistance class CRC | 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Ambient temperature | -20°C-80°C |
| Pneumatic connection | G1/8 |
| Material collar screws | Galvanised steel |
| Material cover | Wrought aluminium alloy |
| Material dynamic seals | NBR TPE-U(PU) |
| Material piston rod | High-alloy steel |
| Material cylinder barrel | Wrought aluminium alloy |
Data sheet
There are so many kinds. Please contact with me!
After-sale Service
We can provide a series of after-sale service, such as product introduction, mounting, debugging, technical support and so on.
