FESTO Compact Cylinder ADN-40-100-A-P-A 536288 Pneumatic Air Cylinders
Price:
EXW USD40-60
MOQ:
1pc
Delivery Time:
7-12working days
Brand:
FESTO
Product Description
FESTO Compact cylinder ADN-40-100-A-P-A 536288 Pneumatic Air Cylinders
About product
Contactless position sensing using proximity switches
Highly flexible thanks to the wide range of variants
Easy to mount with a comprehensive range of mounting accessories for just about every type of installation
Technical Data
| Stroke | 100 mm |
| Piston diameter | 40 mm |
| Mounting position | optional |
| Conforms to standard | ISO 21287 |
| Design | Piston Piston rod Profile barrel |
| Mode of operation | Double-acting |
| Ambient temperature | -40°C-120°C |
| Basic weight for 0 mm stroke | 346 g |
| Additional weight per 10 mm stroke | 37 g |
| Pneumatic connection | G1/8 |
| Note on materials | RoHS-compliant |
| Material collar screws | Steel |
| Material cover | Anodised wrought aluminium alloy |
| Material piston rod | High-alloy steel |
| Material cylinder barrel | Smooth-anodised wrought aluminium alloy |
General technical data
FESTO cylinder has good stability, quality, and long service life, making it your best choice.
