CONVUM MYOUTOKU CV-25HS, CV-30HS, CV-10HSCK CV Series Vacuum Ejectors
CONVUM MYOUTOKU CV-25HS, CV-30HS, CV-10HSCK CV Series Vacuum Ejectors
As a versatile and fundamental component in automation systems, the CONVUM CV Series Vacuum Ejector stands out for its simple design, ease of installation, and application flexibility. The device creates vacuum suction solely from a supply of compressed air, making it incredibly reliable with no electrical components and minimal maintenance requirements beyond ensuring clean, dry air. This makes it particularly valuable in harsh industrial environments. Commonly used for controlling suction cups that handle objects in automation systems, from glass and electronic components to plastic and sheet metal, the CV Series' effectiveness and durability have made CONVUM a benchmark name in the field of vacuum ejection technology.
| Model | Nozzle size(Φmm) | Compatible Silencer |
|---|---|---|
| CV-25HS | 2.5 | MS6-01 |
| CV-30HS | 3 | MS6-01 |
| CV-10HSCK | 1 | MSS-01 |
| Description Model number | Unit | CV-10 | CV-15 | CV-20 | CV-25 | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| HS | LS | HR | HS | LS | HR | HS | LS | HR | HS | LS | HS | ||
| Nozzle size | mm | 1.0 | 1.5 | 2.0 | 2.5 | ||||||||
| Fluid | Non-lubricated compressed air | ||||||||||||
| Ambient temperature | °C | 0~60(No Freezing) | |||||||||||
| Operating pressure range | MPa | 0.1~0.6 | |||||||||||
| Rated pressure | MPa | 0.5 | 0.35 | 0.5 | 0.35 | 0.5 | 0.35 | 0.5 | |||||
| Maximum vacuum pressure | kPa | -92 | -57 | -91 | -92 | -57 | -91 | -92 | -57 | -91 | -92 | -57 | -92 |
| Suction flow | L/min(ANR) | 27 | 36 | 25 | 63 | 95 | 54 | 110 | 155 | 88 | 160 | 250 | 225 |
| Air consumption | L/min(ANR) | 44 | 100 | 180 | 265 | 385 | |||||||
| Description Model number | Unit | CV-CK | |
|---|---|---|---|
| Fluid | Air | ||
| Operating pressure range | kPa | -20～-53 | |
| Withstand pressure | MPa | 0.5 | |
| Ambient temperature range | ℃ | 0～60 (No freezing) | |
| Ambient humidity range | %RH | 35～85 (No condensation) | |
| Switch type | Reed switch, normally opened (N.O) | ||
| Rated voltage | V | AC125, 250 | |
| Maximum load current | AC125 | A | 5 |
| AC250 | A | 3 | |
| Repeatability | kPa | ±5.3 | |
| Hysteresis | kPa | 4.0～13.3 | |
| Cable length | mm | 100 | |
