AIRTAC 2V Series 2V250-20, 2V250-25 2/2 way Brass Fluid Control Valve 3/4", 1"
2V025-06, 2V025-08 AIRTAC 2V Series 2/2 way Brass Fluid Control Valve 1/8" 1/4"
Product Feature:
1.This 2/2 way diaphragm piloted solenoid valve has lowenergy consumption and large air flow .
2. The starting pressure is low and the Min. operationaldifferential pressure is 0.05MPa.
3. The valve body is made of brass which is heat resistanceand the coil conforms to Class B classification . The sealsare made of NBR.
| Item Code | Port Size | Positions |
|---|---|---|
| 2V250-20 | 3/4" | 2/2 way |
| 2V250-25 | 1" | 2/2 way |
| Model | 2V250-20 | 2V250-25 |
|---|---|---|
| Fluid | Air. Water. Oil | |
| Acting | Internally piloted acting | |
| Initial state | Normally closed | |
| Orifice size (mm) | 25.0 | 25.0 |
| Cv | 13.00 | 13.00 |
| Port size [Note] | 3/4" | 1" |
| Viscosity limit | Under 20CST | |
| Pressure range | 0.05~1.0MPa(7~145psi) | |
| Proof pressure | 1.5MPa(215psi) | |
| Material body | Brass | |
| Seal material | NBR | |
| Activating time | 0.05 sec and below | |
[Note] PT thread, G thread and NPT thread are available.
| Valve type | Power type | Frequency (Hz) | Voltage range | Electrical entry | Power Consumption (VA/W) | Insulation | Temp.rise (°C) |
|---|---|---|---|---|---|---|---|
| 2V025 2V130 2V250 | AC | 50 | ±15% | Terminal Grommet | 7.0VA | Class B | 35 |
| 60 | |||||||
| DC | - | ±10% | 7.0W | 45 |
