AEVC-4-2.5-P AEVC-4-5-P AEVC-4-2.5-A-P AEVC-4-5-A-P Festo Single-Acting Short-stroke Cylinders

The Festo AEVC series short-stroke single-acting cylinders are compact pneumatic actuators engineered for applications where space is limited and precise linear motion is required. These cylinders feature a spring-return mechanism, where compressed air drives the piston in one direction, and an internal spring provides the return force. Available in a wide range of bore sizes from 4 mm to 100 mm and strokes from 2.5 mm to 25 mm, they can generate forces between approximately 4.9 N and 4,712 N. Key features include a compact design that optimizes installation space, options for magnetic or non-magnetic pistons for position sensing, and compliance with standards like VDMA 24562 for mounting. They are built from materials such as anodized aluminum and feature seals like NBR, allowing them to operate in temperatures from -20°C to +80°C, making them suitable for automation tasks like clamping, ejecting, and positioning in confined spaces.

The company for the products are brand new original products, no second-hand and refurbished products, or leave a compensable ten and return the full amount , but the buyer due to our purchase of model error is not responsible for returns, another of the company's sales of products enjoy one year from the date of shipment quality assurance , according to the original quality standards , during warranty with product problems , need confirmation testing by the manufacturer , the supplier to be solved , the demand side due to storage , use, poor maintenance caused by lower-quality product , and not raise objections.

You can send a sample to customize the products, we have many engineers can help it; If you want a product of mine, but you are not sure if it's what you want, so you can ask for a sample from me, it will be free.

We can provide a series of after-sale service, such as product introduction, mounting, debugging, technical support and so on.
