SHAKO MSV8632-01PB MSV8632-01PP MSV8632-01PPL MSV8632-01EB 3/2 way Mechanical Valve 1/8"
SHAKO MSV8632-01PB MSV8632-01PP MSV8632-01PPL MSV8632-01EB 3/2 way Mechanical Valve 1/8"
A key feature of the MSV8632 series is its versatility in actuation methods. It is available with various operator types, including a basic button, roller lever (R), one-way roller (RL), twist selector (TB), long twist selector (LB), palm buttons (PB, PP, PPL), and a detent button (EB) for push-pull or stop-cock operation . This allows the valve to be adapted for diverse applications, such as being integrated into moving machinery like cylinder slides . The valve incorporates NBR (Nitrile) seals for reliable performance and boasts a panel mounting bore size of 30mm (with a 25mm option available) for easy installation . Its spool-type design ensures smooth shifting and consistent control force, unaffected by backpressure, and it operates without requiring lubrication.
Order Codes:
| Item Code | Port size | Position | Operator |
| MSV8632-01PB | 1/8" | 3/2 way | Palm button (Mushroom) |
| MSV8632-01PP | 1/8" | 3/2 way | Palm button (Flush) |
| MSV8632-01PPL | 1/8" | 3/2 way | Palm button (Extended) |
| MSV8632-01EB | 1/8" | 3/2 way | Latching button |
Specification:
| Model | MSV8632-01 | MSV8642-01TB |
| Port size | 1/8" | |
| Body material | Aluminum alloy | |
| Panel dimension | 30mm (Option:25mm) | |
| Fluid | Compressed air | |
| Sectional area | 1.8mm² | |
| Operating pressure range | 0 ~ 9 kgf/cm² | |
| Max. operating pressure | 10 kgf/cm² | |
| Ambient temperature | -10°C ~ 60°C | |
| Standard operator color | Black: TB, LB; Red: PB, PP, PPL, EB | |
| Optional color | Green, Black, Yellow for PB, PP, PPL, EB, kgf/cm² | |
Quality Standards:
The company for the products are brand new original products, no second-hand and refurbished products, or leave a compensable ten and return the full amount , but the buyer due to our purchase of model error is not responsible for returns, another of the company's sales of products enjoy one year from the date of shipment quality assurance , according to the original quality standards , during warranty with product problems , need confirmation testing by the manufacturer , the supplier to be solved , the demand side due to storage , use, poor maintenance caused by lower-quality product , and not raise objections.
You can send a sample to customize the products, we have many engineers can help it; If you want a product of mine, but you are not sure if it's what you want, so you can ask for a sample from me, it will be free.
We can provide a series of after-sale service, such as product introduction, mounting, debugging, technical support and so on.
