CP96SDB63-80C CP96SDB63-100C CP96SDB63-125C SMC CP96 Series ISO Cylinder
| Item Code | Bore Size (ø mm) | Stroke (mm) | Type |
| CP96SDB63-80C | 63 | 80 | Double acting |
| CP96SDB63-100C | 63 | 100 | Double acting |
| CP96SDB63-125C | 63 | 125 | Double acting |
| CP96SDB63-80 | 63 | 80 | Double acting |
| CP96SDB63-100 | 63 | 100 | Double acting |
| CP96SDB63-125 | 63 | 125 | Double acting |
| Bore size [mm] | 32 | 40 | 50 | 63 | 80 | 100 | 125 | |
| Action | Double acting | |||||||
| Fluid | Air | |||||||
| Proof pressure | 1.5 MPa | |||||||
| Max. operating pressure | 1.0 MPa | |||||||
| Min. operating pressure | 0.05 MPa | |||||||
| Ambient and fluid temperatures | Without auto switch: -20 to 70°C (No freezing) With auto switch: -10 to 60°C (No freezing) |
|||||||
| Lubrication | Not required (Non-lube) | |||||||
| Operating piston speed | 50 to 1000 mm/s | 50 to 700 mm/s | ||||||
| Allowable stroke tolerance | Up to 500 | +2 0 |
+1.0 0 |
|||||
| 501 to 1000 | +2.4 0 |
+1.4 0 |
||||||
| 1001 to 1500 | +2.8 0 |
+1.8 0 |
||||||
| 1501 to 2000 | +3.2 0 |
+2.2 0 |
||||||
| Cushion | Air cushion on both ends + Bumper cushion | Air cushion | ||||||
| Port size | G 1/8 | G 1/4 | G 1/4 | G 3/8 | G 3/8 | G 1/2 | G 1/2 | |
| Mounting | Basic, Axial foot, Rod flange, Head flange, Single clevis, Double clevis, Center trunnion, Adjustable position trunnion |
|||||||
