4L110-06, 4L210-06/08, 4L310-08/10 AIRTAC 4L Series 5/2 way Manual Push-pull Valve 1/8", 1/4", 3/8"
4L110-06, 4L210-06/08, 4L310-08/10 AIRTAC 4L Series 5/2 way Manual Push-pull Valve 1/8", 1/4", 3/8"
| Type | Port Size | Positions |
| 4L110-06 | 1/8" | 5/2 way |
| 4L210-06 | 1/8" | 5/2 way |
| 4L210-08 | 1/4" | 5/2 way |
| 4L310-08 | 1/4" | 5/2 way |
| 4L310-10 | 3/8" | 5/2 way |
| Model | 4L110-06 | 4L210-06 | 4L210-08 | 4L310-08 | 4L310-10 |
| Fluid | Air (to be filtered by 40 μm filter element) | ||||
| Operating | Manual control direct acting type) | ||||
| Port size[Note1] | 1/8" | 1/4" | 3/8" | ||
| Orifice size(Cv) [Note3] |
10.2mm² (Cv=0.6) |
4L210-08:17.0mm² (Cv=1.0) |
4L310-10:28.0mm² (Cv=1.65) |
||
| Valve type | 5/2 Way | ||||
| Lubrication [Note2] | Not required | ||||
| Pressure range | 0~1.0MPa(0~145psi) | ||||
| Proof pressure | 1.5MPa(215psi) | ||||
| Temperature | -20~70℃ | ||||
| Material of body | Aluminum alloy | ||||
[Note1] PT thread, G thread and NPT thread are available;
[Note2] Once lubricated air is used, continue with same medium to optimise valve life spanIt is suggested to use ISo VG32 lubricant or the oil with the same grade.
[Note3] Eguivalent orifice S and Cv are all calculated from the flow rate data.
