Yellow Pneumatic Tube Fittings Metal Male Thread G1 / 2" Connection Adapter
22SF Series Yellow metal Male Thread 22SF AK21 MXX G1/2" Connection adapter assembly RECTUS Plugs
Interchangeability
RECTUS 22
ARO 210
PARKER 50
CEJN 300
ORION 44510
JWL 552 + JWL 532
various Swiss Products
Working Temperature*
-20°C up to +100°C (NBR)
-40°C up to +120/150°C (EPDM)
-15°C up to +200°C (FKM)
depending on the medium.
Advantages
Single handed operation.
Plug design optimised.
through greater insert depth.
Working Pressure
PB = 35 bar, maximum
static working pressure
with safety factor of 4 to 1.
| 22SF | 22SF AK13 MXX | G1/4" | Plug |
| 22SF AK17 MXX | G3/8" | Plug | |
| 22SF AK21 MXX | G1/2" | Plug |
Size
| Connection A | Hex SW |
L mm |
L1 mm |
Version | Part Number |
| G 1/4 | 14 | 41 | 12 | Brass | 22SF AK13 MXX |
| G 3/8 | 17 | 41 | 12 | Brass | 22SF AK17 MXX |
| G 1/2 | 22 | 46 | 17 | Brass | 22SF AK21 MXX |
