Npt Pneumatic Air Preparation Units Aluminum Alloy Material Lf-1-d-maxi
Air Treatment Unit FESTO LF-1-D-MAXI Aluminum Alloy White NPT Pneumatic Air Control Filter Regulator
Product feature
1. Good particle and condensate separation.
2. With manual, semiautomatic, or fully automatic condensate drain.
3. High flow rate with minimal pressure drop.
4. Choice of filter cartridges: 5 µm or 40µm
| General technical data | ||||||||||
| Size | Micro | Mini | Midi | Maxi | ||||||
| Pneumatic connection | 1/8" | 1/8" | 1/4" | 3/8" | 3/8" | 1/2" | 3/4" | 3/4" | 1" | |
| Operating medium | Compressed air | |||||||||
| Design | Sintered filter with centrifugal separation | |||||||||
| Type of mounting | Via accessories | |||||||||
| In-line installation | ||||||||||
| Assembly position | Vertical ±5° | |||||||||
| Grade of filtration [µm] | 5 | 5 or 40 | ||||||||
| Max. condensate volume [cm3] | 3 | 22 | 43 | 80 | ||||||
| Input pressure [bar] | ||||||||||
| Condensate drain | manual | 0~10 | 0~16 | |||||||
| semiautomatic | 1~10 | - | ||||||||
| fully automatic | - | 2~12 | ||||||||
| Size | Micro | Mini | Midi | Maxi | ||
| Female thread | Port block | Connection 3/4NPT |
Connection 1NPT | |||
| LF-… | 44 | 64 | 250 | 700 | 1340 | 1440 |
| Type | B1 | B2 | B3 | B4 | B5 | D1 | D2 Φ |
D3 | D6 Φ |
H1 | H2 |
| Mini | |||||||||||
| LF-1/8-D-MINI | 64 | 52 | 40 | 30 | - | G1/8 | - | M4 | 38 | 20 | 11 |
| LF-1/4-D-MINI | G1/4 | ||||||||||
| LF-3/8-D-MINI | 70 | G3/8 | |||||||||
| LF-D-MINI | - | - | 5.8 | - | 11 | - | - | ||||
| Midi | |||||||||||
| LF-3/8-D-MIDI | 85 | 70 | 55 | 43 | - | G3/8 | - | M5 | 52 | 32 | 22 |
| LF-1/2-D-MIDI | G1/2 | ||||||||||
| LF-3/4-D-MIDI | G3/4 | ||||||||||
| LF-D-MIDI | - | - | 6.8 | - | 24 | - | - | ||||
| Maxi | |||||||||||
| LF-3/4-D-MAXI | 96 | 80 | 66 | 46 | - | G3/4 | - | M5 | 65 | 32 | 22 |
| LF-1-D-MAXI | 116 | 91 | G1 | 40 | |||||||
| LF-D-MAXI | - | - | 6.8 | - | 30 | - | - | ||||
