KOGANGEI Aluminum alloy TAC2-31P TAC2-41P TAC2-41PP AIR VALVES Push Button Push button spring return type Valves

KOGANGEI Aluminum alloy TAC2-31P TAC2-41P TAC2-41PP AIR VALVES Push Button Push button spring return type Valves

Explanation of operation

Actuation of valve A (3P) extends the rod of cylinder D, which then retracts and stops. It is often used for reliable reciprocating operation.
1 Pressing valve A supplies air to the pilot operator (34A) on the right portion of valve B (4PP), which then switches valve B.
2 As a result, the air previously filled in the rod side (left side) of the cylinder is exhausted from R2 of valve B. At the same time, air entering the
cylinder head side (right side),extends the cylinder rod forward.
3 At this time, when the air passes through the speed controller (SCOF) to enter the cylinder, it opens the check valve inside the SCO-F and
quickly fills in. For exhaust,however, the air is choked and the cylinder rod extends while decelerating.

Specifications

Delivery
1. If the products we have in store, we will send it out ASAP after payment.
2. If the products which were customized, we will complete the production within a specified period of time, and send it out the first time, we can promise it.
3. We have a variety of ways to deliver goods, usually DHL, Fedex, TNL will be normal ways, If you require use of a courier, we can do it.
4. Also we can send by your delivery acount if you want.
