IMI HERION norgren 8010777 AC220V DC24V 3/2 5/2 Aluminium

Medium:
Compressed air filtered, lubricated
or non-lubricated
Operation:
Solenoid, indirectly controlled
Operating pressure:
1 ... 10 bar (14 ... 145 psi)
Nominal size:
6 and 12 mm
Port size:
G1/4, G1/2
Flow direction:
Fixed
Mounting position:
Optional,preferably vertical
Ambient/Media temperature:
-10° ... +50°C (+14° ... +122°F)
Depending on solenoid system.
Air supply must be dry enough to
avoid ice formation at temperatures
below +2°C (+35°F).
Materials:
Housing: Aluminium
Pilot flange: Plastic

Seat seal: NBR

technical specification
