5/2 Way,3/2 Way Mindman Pneumatic Solenoid Valves MVSC220-4E1,MVSC220-4E2
Price:
USD4-10
MOQ:
1 piece
Delivery Time:
within 1-30 working days after payment
Brand:
Mindman or OEM
Product Description
5/2 Way, 3/2 Way Mindman Pneumatic Solenoid Valves MVSC220-4E1, MVSC220-4E2
1.ISO9001:2000, CE marked,
2.Ordering Code: MVSC-220-3E1,E2, MVSC-220-4E1,E2, MVSC-220-4E2C,P.R
3.Port size: 1/4"
4.Medium: air
5.high quality, good price
6.Specification
| Model | MVSC-220-3E1,E2 | MVSC-220-4E1,E2 | MVSC-220-4E2C,P.R | ||
| Вore No. | 8A | ||||
| Port size | PT 1/4 | ||||
| No. of port | 3 | 5 | |||
| No. of position | 2 | 2 | 3 | ||
| Medium | Air | ||||
| Operating pressure range | 2-7 kgf/cm2 | 3-7kgf/cm2 | |||
| Operating pressure(LP) | 0-7kgf/cm2 | ||||
| External pilot pressure(LP) | 2-7 kgf/cm2 | 3-7kgf/cm2 | |||
| proof pressure | 10kgf/cm2 | ||||
| Effective orifice | 18 mm2 | 16mm2 | |||
| Response time | 30 ms | 40 ms | |||
| Ambient temperature | ‘-5~+50℃ (No freezing) | ||||
| Voltage | AC110V, 220V (50/60)Hz, DC24V | ||||
| Power consumption | AC=6/4.9VA, DC=2.5W | ||||
| Available voltage range | ±10% | ||||
| Insulation class | F class | ||||
| Weight | 203 g | 296g | 184g | 292g | 338g |
