gas-fired boiler

Gas-fired,oil-fired Boiler

Unit

WNS6-1.25-Y(Q)

WNS6-1.6-Y(Q)

Rating evaporation capacity

t/h

6

6

Rating steam pressure

Mpa

1.25

1.6

Rating steam temperature

198

204

Boiler thermal efficiency

92.5

92.3

Rating oil and gas consumption

kg/m (Nm3/h)

384 / 450

385 / 451

Electricity consumption

kw

23/45.4 (20.5)

23/45.4 (20.5)

Power supply (AC)

380V, 50Hz

Package measurement L*W* H

M

6.14 * 2.4 * 3.22

6.14 * 2.4 * 3.22

Weight

kg

15000

15000

Exhaust gas temperature

230

231

Method of burning

Pressure fog

Positive pressure combustion

Adjustable method

Automatic

Fuel heating capacity is calculated by the following standard: Light oil: 10200 kcal/kg, Heavy oil:9600 kcal/kg, Natural gas:9000 kcal/Nm3, City burning gas: 4000 kcal/Nm³
