Pasture Solar Powered Electric Fence Energise Lithium Ion Battery 12AH 3.2V 32700 Cell 1S2P Structure
Pasture Solar Powered Electric Fence Energise Lithium Ion Battery 12AH 3.2V 32700 Cell 1S2P Structure
4. This GuangZhou Sunland New Energy Tech.Co.,Ltd LiFePO4 battery is a great option for those who need a reliable and powerful power source. It has amazing high temperature performance, making it perfect for use in electronic fence applications.
|
No. |
Items |
Specifications |
Remark |
|
1 |
Capacity for assembled cell discharging by 0.2C |
≥11.6Ah |
Standard discharging method |
|
2 |
Battery Voltage |
≥3.28 V |
Base on MOQ 10K Within 10 days from Factory |
|
Battery SOC |
Appr 30% | ||
|
3 |
Standard charge condition |
Charge with 2A constant current and 3.65V constant voltage, charge to 3.65V,continue charging till current decline to ≤0.01C |
Charge voltage: 3.65V±0.03V Charge current:2A |
| 4 |
Max continuous charge current |
2A |
|
|
5 |
Standard discharging method |
2A constant current discharge to 2.5 V, |
|
| 6 |
Max continuous discharge current |
2A |
|
|
7 |
Internal Impedance |
Assemblage Impedance |
Measure the Red and black wire of the connector after assembling. |
| 8 |
Charge upper limit temperature |
0-45℃ |
Charging at low temperature, capacity and cycle life will reduce. |
| 9 |
Discharge upper limit temperature |
-20-60℃ | |
| 10 | Connector | JST PHR-4P |
|
| 11 | Wire | UL1007 24AWG |
Outside diameter Max :1.5mm |
| 12 | Date code | Cell date code and battery date code not beyond 3month | |
| 13 | Vbatt(OCV) | 3.75±0.05V |
Pasture Solar Powered Electric Fence Energise Lithium Ion Battery 12AH 3.2V 32700 Cell 1S2P Structure
|
|
|
No |
Working temperature |
Charging Spec |
Discharging Spec |
|
1 |
-20oC to 0oC |
Charge current limited to 0.1C(1.2A) or |
Suggest discharge current limited to 0.2C or |
| 2 | 0oC to 45oC | Charge current within spec | Discharge current within spec |
|
3 |
45oC to 70oC |
Charge current limited to 0.1C(1.2A) or below Cut off voltage 3.60Vor below |
Suggest discharge current limited to 0.2C or below |
|
|
