50KWH ESS Energy Storage System 230.4V 150AH LiFePO4 Battery With Cabinet Air Cooling
50KWH Commercial ESS Energy Storage System 230.4V 150AH LiFePO4 Battery With Cabinet Air Cooling
Spec:
| Item | Parameter |
| Battery Module | 76.8V 150AH |
| Module Qty | 4 |
| Battery Capacity | 46KWH |
| Normal Voltage | 230.4V |
| Working voltage Range | 212.4V-255.6V |
| Dimension(mm) | 850*650*1700 |
| Weight | 450kg |
| Battery Type | LiFePO4 |
| Assembling method | Floor type |
| Class of protection | IP55 |
| Standard Charge and discharge current | 200A |
| Working temperature | -10-50℃ |
| lifetime | 10 years |
| System controller | P720 |
| Communication port | RS485 |
50KWH Commercial ESS Energy Storage System 230.4V 150AH LiFePO4 Battery With Cabinet Air Cooling
50KWH Commercial ESS Energy Storage System 230.4V 150AH LiFePO4 Battery With Cabinet Air Cooling
Cycle Life:
At the ambient temperature of 25 ± 2 ℃ , charge at the required current. When the battery voltage reaches the upper limit limit voltage of charging, change to constant voltage charging until the charging current is less than or equal to 0.02c, After standing for 0.5h, the current shall be discharged to 80% DOD, and the above steps shall be repeated for cyclic charging and discharging. When the discharge capacity for three consecutive times is less than 80% of the initial capacity, the life shall be terminated, and the cycle life shall be ≥ the required cycle times.
