High Stability Low PDL 1480 / 1550nm WDM Optical Fiber Splitter For C Band EDFA
High Stability Low PDL 1480 / 1550nm WDM Optical Fiber Splitter For C Band EDFA
Quick Details
Brand Name: DYS
Model Number: High Stability Low PDL 1480 / 1550nm WDM
Directivity(dB)≥55
Package size (mm):Φ3.0*50
Return Loss(dB):UPC:50 APC:60
Operating Temperature(°C):-40~85
Cable Type(mm):0.25, 0.9, 2.0, 3.0
|
Parameters |
|
|
Wavelength (nm) |
1480 /1550 |
|
Bandwidth (nm) |
± 20 |
|
Wavelength isolation(dB) |
19 |
|
PDL(dB) |
0.10 |
|
Directivity (dB) |
≥55 |
|
Operating temperature(℃) |
- 40 ～ + 70 |
|
Storage temperature(℃) |
- 40 ～ + 85 |
|
Package dimensions (mm) |
Φ3.0*50 |
Competitive Advantage
DYS strictly enforce the ISO9001 quality management system, companies with good facilities and qualified human resources management to ensure product quality stability and excellent performance; and good after-sales service, to win the trust of customers, products exported to Europe and the United States and Southeast Asian countries.
Certificate of qualification
