China Home Armoured Blue 2.9mm (1core, 2core) Outer Diameter Optical Fiber Patch Cord for sale

Home Armoured Blue 2.9mm (1core, 2core) Outer Diameter Optical Fiber Patch Cord

Price Negotiable

Price: Negotiable

MOQ: Negotiable

Delivery Time: 2days

Brand: DYS/OEM

Product Description

Home Armoured Blue 2.9mm (1core, 2core) Outer Diameter Optical Fiber Patc

Quick Details

Place of Origin: Guangdong, China (Mainland)
Brand Name: DYS/OEM
Fiber type: Armoured
Inserion Loss: <0.3db
Return Loss: >45db
Certifaction: ISO9001, ROHS
Color: Grey

Packaging & Delivery

Packaging Details:	Individual box or according to customer's request
Delivery Detail:	In 3 days

Features

SC, LC, ST and FC connectors

Available in low smoke zero halogen (LSZH) jacket

Conforms to IEC, EIA-TIA or Telcordia performance requirements

Available in different fibre types

Available in standard and custom lengths

REACH, SvHC and RoHS materials compliant

Applications

CATV / VIDEO

Passive Optical Network PON

FTTX

ATM, SONET and WDM

Military applications

Parameters	Standard Fiber Cable Assemblies
Fiber Type	SM(G.652/G.657A)	MM(OM1/OM2/OM3)
Jacket Materials	LSZH/OFNR/PVC
Connector Type	SC/LC/ST/LC/MU/MTRJ/MPO/E2000
Ferrule Materials	Ceramic
Testing Wavelengths	1310±30/1550±30nm	850±30/1300±30nm
Insertion Losss(dB) TIA/EIA-455-107	≤ 0.3dB (PC/UPC/APC)	≤ 0.3dB (PC/UPC)
Return Loss(dB) TIA/EIA-455-107	≥45dB(PC/UPC) ≥55dB(APC)	≥35dB(PC/UPC)
Exchangeability	≤ 0.2dB
Cable Assemblies	Pigtail/Simplex/Duplex/Fan-out Patchcord
Operating Temperature (° C)	-10~ + 70
Storage Temperature (° C)	-40 ~ +85
Package	1unit/bag
*All values specified are with connectors.

Competitive Advantage

DYS strictly enforce the ISO9001 quality management system, companies with good facilities and qualified human resources management to ensure product quality stability and excellent performance; and good after-sales service, to win the trust of customers, productsexported to Europe and the United States and Southeast Asian countries.

Certificate of qualification
