Flatness Z Purlin Roll Forming Machinery With 15 Rows Rollers
Flatness Z Purlin Roll Forming Machinery With 15 Rows Rollers
Introduction and Guarantee :
1. This machine contains our experiences in 30 years and many times improvements by our engineers.
2. In our service, we support the equipments and profiles that customers really need and including our most sincere recommends.
3. Our roll forming machines are driven by chain in hydraulic system. Chain Drive System can save the power compare with other system. That also means that customers do not need to pay the extra power fee during production of steel panel.
Main specification:
| Install size | 13500mm*2200mm*1500mm |
| Rollers | 15 rows |
| Rolling material | Gcr 15 |
| Main motor power | 11 KW |
| Hydraulic unit power | 11 KW |
| Pressure of the hydraulic unit | 18-20Mpa |
| Productivity | 9-10 m/min |
| Punching material | Cr12 |
| Electric control system | PLC vector inverter |
| Raw material thickness | 1.5-3.0mm |
| Forming standard | 80-300 |
Z Shaped Purlin Forming Machine:
Usage:shape purlin | Model | Section size | |||
h(mm) | b1(mm) | b2(mm) | t(mm) | ||
| Z100 | 100 | 50 | 54 | 2.0-2.5 |
Z100 | 100 | 50 | 54 | 2.0-3.0 | |
Z120 | 120 | 50 | 54 | 2.0-3.0 | |
Z120 | 120 | 50 | 54 | 2.0-3.0 | |
Z140 | 140 | 50 | 54 | 2.0-3.0 | |
Z150 | 150 | 60 | 64 | 2.0-3.0 | |
Z150 | 150 | 60 | 64 | 2.0-3.0 | |
Z160 | 160 | 60 | 64 | 2.0-3.0 | |
Z160 | 160 | 60 | 64 | 2.0-3.0 | |
Z180 | 180 | 70 | 74 | 2.0-3.0 | |
Z180 | 180 | 70 | 74 | 2.0-3.0 | |
Z200 | 200 | 70 | 74 | 2.0-3.0 | |
Z200 | 200 | 70 | 74 | 2.0-3.0 | |
Z220 | 220 | 80 | 84 | 2.0-3.0 | |
Z220 | 220 | 80 | 84 | 2.0-3.0 | |
Z240 | 240 | 80 | 84 | 2.0-3.0 | |
Z240 | 240 | 80 | 84 | 2.0-3.0 | |
