Color Steel Glazed Tile Roll Forming Equipment , 5.5 Kw Main Motor Power Roll Former Machine

Color Steel Glazed Tile Roll Forming Equipment , 5.5 Kw Main Motor Power Roll Former Machine

   A). Main Components

   B). Working Flowing

Decoiler --- Feeding Guide --- Film Covering --- Roll Forming --- Pressing --- Cut-to-length --- Run out table

   C). Main Specifications

• Material thickness: 0.3-0.7mm
• Material width: depend on customer’s requirement
• Decoiler Type: manual or automatical type ( depend on customer’s requirement )
• Weight Capacity Of Decoiler: 5 Ton
• Main Motor Power: 5.5 Kw
• Hydraulic Motor Power: 11 Kw
• Forming Station: 13-22 ( depend on profile drawing )
• Material of Roller: High grade 45# forge steel, Polished and coated with 0.05mm Chrome Surface.
• Main Axis Material: High grade 45#, quenched and heat treatment.
• Axis Diameter: ¢ 75mm
• Working Speed: 0-15 m/min
• Transporting Type: Chain Transmission
• Heat Treatment of Cutting Blade: HRC 50-60
• Type of Cutting: Hydraulic cutting
• Material Of Cutting Blade: C r 12
• Heat Treatment of Cutting Blade: HRC 50-60
• Machine Frame stand: Welded structural steel
• Thickmess of Fame Steel: 18mm
• Electrical Control: PLC Frequency Control System with touch screen
• PLC: PANASONIC Brand
• Encoder: OMRON Brand
• Transducer: PANASONIC Brand
• Machine Weight: about 8.5 Ton



   D). Applications

Glazed tile; Roof Tile; Metal roof tile; Steel roof tile; Color steel tile; Color glazed tile; Wave tile; Steel roofing sheet; Metal roof panel; Steel roof panel; Roof wall cladding; Roof cladding; Wall cladding

   E). More Pictures
