CE Cold Roll Forming Machine for Sigma Shape / Sigma Purlin / Sigma Post / Guardrail Post

This sigma post roll forming machine adopt galvanized steel coil production material to form sigma post profiles through 5 Ton decoiler, pinch feeding, main roll forming part,  Hydraulic punching & cutting and Non-power type support tables.

   A).  Main Components

1. Hydraulic Decoiler ---------------------------------------------- 1 Unit
2. Leveling and Feeding Guide ---------------------------------- 1 Unit
3. Roll Forming Machine ------------------------------------------- 1 Unit
4. Punching Device ------------------------------------------------- 1 Unit
5. Hydraulic Cutting ------------------------------------------------- 1 Unit
6. Hydraulic Station ------------------------------------------------- 1 Unit
7. PLC Contol System ----------------------------------------------- 1 Unit
8. Runout Table ------------------------------------------------------- 1 Unit
9. Spare Coupling ----------------------------------------------------- 1 Unit

   B). Main Specification

1. Material thickness: 4mm
2. Main power: 21KW
3. Forming Station: 16 steps
4. Cutting power: 7.5KW
5. Drive: Gearbox gimal transmssion
6. Roller Material: GCr15 steel, quenched and heated process
7. Shaft material: 45# Steel, heated and quenched treatment
8. Machine frame: Welded structural steel
9. Machine base: 36# H steel
10. Thickness of Frame steel: S18


   C). Sigma Post Drawing for reference

   D). Applications

Sigma post, guardrail post, sigma section, sigma profile, sigma shape, sigma purlin...

   E). Competitive Advantages

High Quality

Reasonable Price

Good after Service

1 Year Warranty

More Than 10 Years Experience

   F). Reference Pictures
