Material Thickness 0.3-0.7mm Roof Roll Forming Machine With Working Speed 0-20m/min

   Main Specification

• Material thickness: 0.3-0.8mm
• Material width: depend on customer’s requirement
• Decoiler Type: manual or automatical type ( depend on customer’s requirement )
• Weight Capacity Of Decoiler: 5 Ton
• Main Motor Power: 5.5 Kw
• Hydraulic Motor Power: 3 Kw
• Forming Station: 13-20 ( depend on profile drawing )
• Material of Roller: High grade 45# forge steel, Polished and coated with 0.05mm Chrome Surface.
• Main Axis Material: High grade 45#, quenched and heat treatment.
• Axis Diameter: ¢ 75mm
• Working Speed: 0-15 m/min
• Transporting Type: Chain Transmission
• Heat Treatment of Cutting Blade: HRC 50-60
• Type of Cutting: Hydraulic cutting
• Material Of Cutting Blade: C r 12
• Heat Treatment of Cutting Blade: HRC 50-60

   Product Description

   Roofing sheet roll forming machines are extensively used in building steel-structure large-scale                  warehouses, plants, supermarkets, shopping malls, trade markets, stadiums, holiday villages,                    hotels, villas, residences and different kinds of greenhouses.

   Main Components

   Decoiler ---------------------------------------------- 1 Unit

   Feeding guide -------------------------------------- 1 Unit

   main roll forming machine ------------------------ 1 Unit

   Hydraulic cutting device -------------------------- 1 Unit

   Hydraulic Station ----------------------------------- 1 Unit

   PLC computer control ----------------------------- 1 Unit

   Output table ---------------------------------------- 1 Unit

   Work Flowing

   Decoiler --- Fedding Guide --- Roll Forming --- Cut-to-length --- Run out table

   Profile Drawing

   Application

   Metal roof; steel roof; metal roof wall panel; steel roof wall panel; metal roofing sheet; steel roofing        sheet; metal roof panel; steel roof panel; roof wall cladding; roof cladding; wall cladding

   Advantages

• High Quality
• Reasonable Price
• Good after Service
• 1 Year Warranty
• More Than 10 Years Experience

   Machine Pictures
