16 Forming Stations Steel Shelf Roll Forming Machine With Galvanized Coil Or Carbon Steel, Forming Speed 12-15m/min

   Main Specifications of Steel Shelf Forming Machine

• Suitable Material: thickness 2.0-2.5mm, Galvanized coil or carbon steel
• Working Speed: 12-15m/min
• Forming Stations: 16 stations
• Roller Material: Cr12Mov, Quench HRC58-62
• Shaft Material: 45# Advanced Steel
• Shaft Diameter: 75mm
• Total power: 22.5kw
• Decoiler: Manual decoiler or Auto Decoiler or Hydraulic Decoiler (Depend on customer's requirement)
• Drive Type: Chain Drive
• Punching Type: Hydraulic punching
• Cutting Blade: Cr12Mov, quench HRC58-62
• Cutting Type: Hydraulic cutting
• The whole machine is controlled by industry computer-PLC
• PLC: PANASONIC Brand
• Encoder: Omron
• Inverter: YASKAWA Brand
• Weight of Machine: About 13T

   Main Components of Steel Shelf

   Working Flow

Decoiler – Feeding - Leveling– Servo Feeding –Hydraulic Punching – Pinch Feeding --- Main Roll Forming – Straightness Device – Hydraulic Cutting -- Run out table

   Steel Shelf Profile Drawing

   Application

Storage rack, storage shelf, Steel rack,steel shelf, rack beam

   Out put Table Products

   Our Advantages

• High Quality
• Reliable
• Durable
• Reasonable Price
• Good after Service
• 1 Year Warranty
• More Than 10 Years Experience
