TG111-HRP10NYRL / TG111-HRPE10NYRL POE Transformer 1000Base-T LP82425ANL
Price:
$0.06-$3.2
MOQ:
400/2000/10K/25K
Delivery Time:
Stock
Brand:
LINK-PP
Product Description
TG111-HRP10NYRL / TG111-HRPE10NYRL POE Transformer 1000Base-T LP82425ANL
- TG111-HRP10NYRL / TG111-HRPE10NYRL => LP82425ANL 【Mass Production Model】
- Meet The Isolation,Insertion Loss and Return Loss Requirements of IEEE802.3
- Available Industry Standard and Low Profile Packages
- Isolation Modules are Available for Most LAN IC Manufacture’s Products
| TG111-HRP10NYRL / TG111-HRPE10NYRL POE Transformer 1000Base-T LP82425ANL | |
| LINK-PP Part Number | LP682425ANL |
| Speed | 10/100/1000BASE-T |
| Number of Ports | SINGLE |
| Application - LAN | ETHERNET (PoE) |
| Package | SMD |
| Temperature | -40℃ TO +85℃ |
| AutomDX | YES |
| Comment | SAME AS NL VERSION |
| Configuration RX | T,C,S |
| Configuration TX | T,C,S |
| Construction | OPEN FRAME |
| Cores Per Port | 8 |
| Package Height (mm) | 5.72 |
| Package Length (mm) | 18.80 |
| Package Width (mm) | 13.64 |
| Turns Ratio RX | 1CT:1CT |
| Turns Ratio TX | 1CT:1CT |
