Variable Frequency Household Gasoline Generator Silent 5KW
Variable Frequency Household Gasoline Generator 5KW Gasoline Silent Generator
Main Features:
1. The working speed of the engine can be changed in a large range, so it can be well matched with the generator to achieve the purpose of saving fuel;
2, the engine can work in the high speed zone, so the output of the same power, engine weight, volume are much smaller. The term is liter power, higher specific power;
3, the alternator working speed is high, also reduce the weight and volume;
4, comprehensive 2, 3 points, but also save a lot of metal materials;
5, the output power supply of high quality - pure sine wave output, harmonic content is very small;
* Oil-water separator
* Oil pre-heater
* Spit-type daily fuel tank
* Standard container
* Rain-proof case
* Sound-proof container
* Trailer
Engine Data:
|
Manufacturer / Model: |
DCEC Cummins 6CTA8.3-G2, 4-cycle |
|
Air Intake System: |
Turbo, Water/Air Cooling |
|
Fuel System: |
PB/W type fuel pump |
|
Cylinder Arrangement: |
6 in line |
|
Displacement: |
8.3L |
|
Bore and Stroke: |
114*135(mm) |
|
Compression Ratio: |
17:1 |
|
Rated RPM: |
1500rpm |
|
Max. Standby Power at Rated RPM: |
180KW/244HP |
|
Governor Type: |
Electronic |
|
Exhaust System |
|
|
Exhaust Gas Flow: |
34.7m3/min |
|
Exhaust Temperature: |
570℃ |
|
Max Back Pressure: |
10kPa |
|
Air Intake System |
|
|
Max Intake Restriction: |
6kPa |
|
Burning Capacity: |
12.4m3/min |
|
Air Flow: |
238m3/min |
|
Fuel System |
|
|
100%( Prime Power) Load: |
215 g/Kw.h |
|
75%(Prime Power) Load: |
211 g/Kw.h |
|
50%(Prime Power) Load:: |
216 g/Kw.h |
|
100%( Prime Power) Load: |
39.7L /h |
|
Oil System |
|
|
Total Oil Capacity: |
23.8L |
|
Oil Consumption: |
≤4g/kwh |
|
Engine Oil Tank Capacity: |
18.9L |
|
Oil Pressure at Rated RPM: |
276-414kPa |
|
Cooling System |
|
|
Total Coolant Capacity: |
34L |
|
Thermostat: |
82-95℃ |
|
Max Water Temperature: |
104℃ |
|
Alternator Data |
|
|
Number of Phase: |
3 |
|
Connecting Type: |
3 Phase and 4 Wires, “Y” type connecting |
|
Number of Bearing: |
1 |
|
Power Factor: |
0.8 |
|
Protection Grade: |
IP23 |
|
Altitude: |
≤1000m |
|
Exciter Type: |
Brushless, self-exciting |
|
Insulation Class, Temperature Rise: |
H/H |
|
Telephone Influence Factor (TIF): |
＜50 |
|
THF: |
＜2% |
|
Voltage Regulation, Steady State: |
≤±1% |
|
Alternator Capacity: |
182KVA |
|
Alternator Efficiencies: |
92.4% |
|
Air Cooling Flow: |
0.514m3/s |
