6 Cylinder Lovol Generator , 1500RPM Generator , 1006TAG , Diesel OEM
6 Cylinder Lovol Generator , 1500RPM Generator , 1006TAG , Diesel OEM
parameter:
Manufacturers provide detailed installation guidelines to ensure proper functionality, reliability and low maintenance costs. When purchasing a generator online, make sure it comes with installation instructions and a product description. The guide covers the following:
Size and Type selection - Typical load of electrical equipment, expected load of appliCAT-parts-partsion
Electrical Factor - Peak load with stability, allowed appliCAT-parts-partsion
Cooling - Engine cooling during power generation
Ventilation - Allowing airflow during cooling (design)
Fuel storage - How long the generator runs at a specific rate of utilization
Noise-db levels for specific models
Exhaust volume - ppm (parts per million) of certain elements, considering the environment and the surrounding environment of the generator
Start system - key start, pull start, button start, etc
|
Prime power(Kw)1500rpm |
121 |
|
Standby power(Kw)1500rpm |
134 |
|
Prime power(Kw)1800rpm |
134 |
|
Standby power(Kw)1800rpm |
147 |
|
Overall dimensions |
1600*800*1064 |
|
Dry weight(Kg): |
730kg |
|
Model |
1006TAG |
|
Main parameters: |
|
|
Prime power(Kw)1500rpm |
121 |
|
Standby power(Kw)1500rpm |
134 |
|
Prime power(Kw)1800rpm |
134 |
|
Standby power(Kw)1800rpm |
147 |
|
Cylinder number |
6 |
|
Cylinder arrangement |
In line |
|
Bore * stoke(mm) |
100*127 |
|
Displacement(L) |
5.99 |
|
Aspiration: |
Turbocharged and air-to-air intercooled |
|
Cycle: |
4-stroke |
|
Combustion system: |
Direct injection |
|
Compression ratio: |
17.5:1 |
|
Total lubriCAT-parts-partsion capacity(L): |
16.1 |
|
Total coolant capacity: |
22.8L |
|
Overall dimensions |
1600*800*1064 |
|
Dry weight(Kg): |
730kg |
| COMPARATION | ||||
| PERKINS | GSKA | |||
| Model | Power(kW) | Model | Power(kW) | |
| 50HZ/1500RPM | 1103A-33G | 28 | 1003G | 28 |
| 1103A-33TG1 | 42 | 1003TG | 44 | |
| 1103A-33TG2 | 53.8 | 1004TG1A | 52 | |
| 1104A-44TG1 | 58.4 | 1004TG | 65.7 | |
| 1006TG1A | 83 | 1006TG1A | 84.3 | |
| 1006TG2A | 91 | 1006TG2A | 92.3 | |
| 1006TAG | 121 | 1006TAG | 121 | |
| 60HZ/1800RPM | 1103A-33G | 32.2 | 1003G | 30 |
| 1103A-33TG1 | 48.8 | 1003TG | 50 | |
| 1103A-33TG2 | 61.2 | 1004TG1A | 58 | |
| 1104A-44TG1 | 68.6 | 1004TG | 75.6 | |
| 1006TG1A | 96.5 | 1006TG1A | 97.6 | |
| 1006TG2A | 107 | 1006TG2A | 108.4 | |
| 1006TAG | 134 | 1006TAG | 134 | |
Remark: diesel engine for genset
Customer Support Services:
Ø Installation
Ø Training (Training customer employees)
Ø Calibration
Ø Preventative maintenance
Ø Replacement parts
Ø Assistance via phone or internet
