80kw Natural Gas Generator 6 Cylinder 4 Stroke 1500rpm 1006TNG Black
80kw Natural Gas Generator 6 Cylinder 4 Stroke 1500rpm 1006TNG Black
Island operation mode:
One or more diesel generators that operate without being connected to the grid is called island operation mode. Working generators in parallel can achieve better efficiency under partial load. An isolated plant for the main power supply of an isolated community will typically have at least three diesel generators, any two of which are rated to carry the required load.
Generators can be electrically connected by a synchronization process. Synchronization involves matching voltage, frequency and phase before connecting the generator to the system. Failure to synchronize prior to connection may result in high short-circuit currents or wear on the generator or its switchgear. The synchronization process can be done automatically by an automatic synchronization module or manually by a guided operator. The automatic synchronizer will read the voltage, frequency and phase parameters from the generator and bus voltage while adjusting the speed via the engine governor or ECM (engine control module).
Loads can be shared between generators operating in parallel through load sharing. Load sharing can be achieved by using a descent rate control controlled by the generator frequency, while it continuously adjusts the engine fuel control to transfer the load to or from the residual power supply. The diesel generator will take on more of the load as the fuel supply to its combustion system increases, while releasing the load if the fuel supply decreases.
product description:
| Generator | Genset Model | GSKA-80 |
| Rated Frequency | 50HZ | |
| Power Factor | 0.8 | |
| Rated Voltage | 400/230V | |
| Rated Power (KW/KVA) | 80/100 | |
| Standby Power (KW/KVA) | 88/110 | |
| Phase/Wire | 3Ph, 4Wr | |
| Overall Size (mm) | 2200×845×1650 | |
| Weight (kg) | 1220 | |
| Engine | Brand | Lovol |
| Model | 1006TNG | |
| Type | Closed water-cooled,in line,4-stroke,1500RPM | |
| Rated Power(kw) | 100 | |
| Intake Type | TUR | |
| No. of Cylinder | 6.L | |
| Bore×Stroke(mm) | 100×127 | |
| Piston Speed (m/s) | 7.62 | |
| Compression Ratio | 10.5:01 | |
| Mechanical Governor Rated | ≦5% | |
| Electronical Governor Rated | ≦1% | |
| Noise Level (dBA) | ≦95 | |
| Exhaust Temperature (℃) | 600 | |
| Lube Oil Capacity(L) | 11 | |
| Rated gas Consumption(CUM/kwh) | 0.33 | |
| Alternator | Model | ISD80 |
| Rated Power(KW/KVA) | 80/100 | |
| Power Efficiency | 88.60% | |
| Voltage Regulation | ≦±1 | |
| Excitation Type | Brushless | |
| Insulation Class | H |
