Anodised Fan Blade Aluminium Industrial Profile Extrusions High Volume Low Speed
Anodised Fan Blade Aluminium Industrial Profile Extrusions High Volume Low Speed
Description:
| NO. | ITEM | Aluminum Fan Blade |
| 1 | Material | Aluminum alloy 6000 series |
| 2 | Temper | T4/T5/T6 |
| 3 | Length | Up to 12 meters |
| 4 | Width | 140MM to 240mm |
| 5 | Height | Up to 40 mm |
| 6 | Wall thickness | At least 1 mm |
| 7 | Surface finish | Anodic Oxidation,powder coating,etc. |
| 8 | Standard China | GB5237-2008 |
| 9 | Packing way | Packed with EP foam individually |
| 10 | Manufacturing process | Aluminum extrusion process |
Specifications:
Chemical composition
|
Alloy |
Si |
Fe |
Cu |
Mn |
Mg |
Cr |
Zn |
Ti |
Impurity |
Al |
|
6063 |
0.2-0.6 |
0.35 |
0.1 |
0.1 |
0.45-0.9 |
0.1 |
0.1 |
0.1 |
0.15 |
Rest |
|
6061 |
0.4-0.8 |
0.7 |
0.15-0.4 |
0.15 |
0.8-1.2 |
0.04-0.35 |
0.25 |
0.15 |
0.15 |
Rest |
|
6060 |
0.3-0.6 |
0.1-0.3 |
0.1 |
0.1 |
0.35-0.6 |
- |
0.15 |
0.1 |
0.15 |
Rest |
|
6005 |
0.6-0.9 |
0.35 |
0.1 |
0.1 |
0.40-0.6 |
0.1 |
0.1 |
0.1 |
0.15 |
Rest |
2)Mechanical property
|
Alloy |
Temper |
Tensile strength |
Yield strength |
Elongation |
|
6063 |
T5 |
≥ 160Mpa |
≥ 110Mpa |
≥ 8% |
|
T6 |
≥ 205Mpa |
≥ 180Mpa |
≥ 8% |
|
|
6061 |
T6 |
≥ 265Mpa |
≥ 245Mpa |
≥ 8% |
Competitive Advantage:
1)Engineering design and support.
2)Deeply processing of Industrial Fan Blade :cutting,punching,drilling,milling,and fabricating.
3)High Quality system, strictly inspection during production and whole inspection before package.
4)Good performance, product warranty for 15 years.
Applications:
Industrial Fan Blade used in factory, buildings, trains machinery ,electronics, medical and other industrial filed .
