Anodized / Powder Painted Aluminium Profile System T Slotted Extruded Aluminum Framing
Anodized / Powder Painted Industrial Aluminium Profile System T Slotted Extruded Aluminum Framing
Product Details
| Product Name | Industrial aluminium profile /aluminum extrusion |
| Material | 6063 aluminium alloy |
| Size | 15/20/30/40/60/80/90/100 series etc. |
| Temper | T4 T5 T6 T66 |
| Slot Width | 6MM,8MM,10MM |
| Color | Natural silver,can be customised. |
| Surface | Mill finish,Anodizeding,Sand Blasting,Powder coating,etc. |
| Deep processing | Cutting,Drilling,Treading,Bending,etc. |
| Application | Building,Industry,Machinery |
| Certification | ISO9001 |
Surface treatment
| Surface treatment | Mill-finish,Anodized,Powder coated,Electropheresis,Wood grain,Brushed, Polishing |
| Anodized thickness | 8 - 25um |
| Anodized Color | Silver,black,chanpagne,bronze,gold or customized |
| Electropheresis Color | Silver,black,chanpagne,bronze,gold or customized |
| Powder coated Color | All color by RAL ,or customer's color sample |
| Powder coated thickness | 40 - 120um |
| Wood grain | customized |
| Guarantee | surface Brightly can be stable for 10 - 20years |
Applications:
Mainly used for industrial production , such as automation equipment , enclosure of the skeleton and the companies according to their own customized mold machinery and equipment , such as assembly line conveyor , hoist, dispenser, testing equipment, shelves , etc., electronic machinery industries and clean room with a gain majority.
Competitive Advantage:
1. Cost advantage
• No mechanical machining necessary request
• Errors in construction or assembly can be rectified more easily
2. Simple
• Just order and assemble using standard t slot aluminum profile and accessories for any structures.
3. Compatibility
• T slot aluminum profile can be combined with products in other ranges
4. Appearance
• Connection not visible from outside and therefore not a disruptive factor when using accessories
5. Resistance
• T slot aluminum profile cross-section is not weakened by drill holes or milled slots
• T slot aluminum profile is secured against twisting by the connecting technology
