China CIVL Heavy Duty Truck Compact Garbage Truck Heavy Cargo Truck, Rubbish Truck, Garbage Truck,25/30m3
| Item | SINOTRUK SWZ 4X2 CARGO TRUCK |
| Truck model | ZZ1251M3211 |
|
Maximum output |
290 hp (196 Kw) at 2200 rpm Option: 290/336/371hp |
| Engine model | WD615.87, Euro II emission standard |
| Clutch | Single-plate dry coil-spring clutch, diameter 420 mm,hydraulically operating with air assistance |
| Front Axles | HW08 |
| Rear Axles | HW1667 |
| Steering |
ZF power steering, model ZF8098, hydraulic steering with power assistance Ratio: 26.2 |
| Tires | 12.00-20 tube Option: 12R20 tube, 12.00-24 tube, 12R24 tube, 12R22.5 tubeless |
| Air conditioner | With safety belts for driver and co-driver;With air conditioner |
| Transmission | HW15710/HW18710,10 speed |
| Export Markets | South America, Southeast Asia, Africa, Mid East, Eastern Asia |
|
Loading Capacity |
8-20T |
| Driver's Cab | HW70 Standard cab |
5:Deppartment : International trade
Cabin:
North Benz long cabin, one sleeper, A/C
Radio player(with USB), Safety belt, Adjustable air type, high back and shock absorption
Driver seat with handle and seatbelts
Dash board with all necessary gauges such as (km meter, rpm, oil pressure, temperature, air pressure,Fuel level)
Headlight, Sun protection on cabin.
Engine:
Engine brand: Weichai
Engine model: WP10.380E32 EURII EGR
Engine type: Diesel 4-stroke direct injection engine, 6-cylinder in-line
With water cooling, turbo-charging & inter-cooling with exhaust valve brake.
Displacement: 11.596 liters
Max. Output: 380HP@353kW
Max torque: 1970NM@1200-1500rpm
Bore/Stroke(mm): 126/155
Clutch:
Clutch: Φ 430 Diaphragm type
Type: Single dry frictional disc, Hydraulic boosting
Gear box:
Model: Fuller 12 speeds(12JS200T), manual, 12-forward and 2 reverse speeds
Steering: TAS85
Brake system:
Double-circulate brake system
