Light Duty Dump Trucks T - Series 4 * 2 Adjustable Steering Wheel Clutch Booster
Price:
Negotiable
MOQ:
1
Delivery Time:
Within 35 days
Brand:
CIVL
Product Description
| Brand | T1 | T1 | |
| Basic Information | Cabin | Standard | Extended |
| Wheelbase(mm) | 2800 | 3250 | |
| Overall demensionmm(mm) | 5400/5200×2100×2400 | 5700/5750×2100×2400 | |
| Cargo Inner Demension(mm) | 3450/3245×1900×750 | 3450×1900×(500+250) | |
| Min.Ground clearance(mm) | 200 | 200 | |
| Rated payload(Kg) | 3000 | 5000/4000 | |
| GVW(Kg) | 6490/6770 | 8230/7650 | |
| Max.speed(km/h) | 75/81.5 | 75/70 | |
| Engine&Transmission | Fuel Type | Diesel | Diesel |
| Emission | EuroI | EuroI | |
| Engine type | Yunnei4100 | Yunnei4100 | |
| Rated power(KW/rpm) | 58.8/66.2/3200 | 58.8/66.2/3200 | |
| Max.torque(N.m/rpm) | 201/2000~2200 | 201/2000~2200 | |
| Steering system | Machanical steering | Power assisted steering | |
| Transmission model | 5MT | 5MT | |
| 530H | 530H | ||
| Brakes&Tyres | Service brake | Air brake | Air brake |
| Parking brake | Air-cut brake | Air-cut brake | |
| Auxiliary brake | - | - | |
| Tyres model | 7.50-16 | 7.50-16 | |
| Equipment | Heater | S | S |
| Adjustable steering wheel | S | S | |
| Power steering | ○ | S | |
| Exhaust brake | - | - | |
| Preheat | S | S | |
| Air deflector | - | - | |
| Air-conditioning | - | - | |
| Clutch booster | S | S | |
| Electric control window | ○ | ○ | |
| SABS | - | - | |
| Disc brake | - | - | |
| ABS | - | - | |
| S:Standard ○:Under developed -:Undeveloped | |||
| Brand | T2 | T2 | |
| Basic Information | Cabin | Extended | |
| Wheelbase(mm) | 3250 | 3250 | |
| Overall demensionmm(mm) | 5760×2200×2480 | 5980×2180×2645 | |
| Cargo Inner Demension(mm) | 3500×2000×(500+250) | 3700×1980×(800+200) | |
| Min.Ground clearance(mm) | 200 | 200 | |
| Rated payload(Kg) | 6000 | 8000 | |
| GVW(Kg) | 10090 | 13790 | |
| Max.speed(km/h) | 78 | 77 | |
| Engine&Transmission | Fuel Type | Diesel | Diesel |
| Emission | EuroII | EuroII | |
| Engine type | Yunnei4102 | Xichai4102 | |
| Rated power(KW/rpm) | 85/3000 | 70.6/3200 | |
| Max.torque(N.m/rpm) | 320/2000~2200 | 245/2000~2200 | |
| Steering system | Power assisted steering | Power assisted steering | |
| Transmission model | 5MT | 5MT | |
| 540H | 540H | ||
| Brakes&Tyres | Service brake | Air brake | Air brake |
| Parking brake | Air-cut brake | Air-cut brake | |
| Auxiliary brake | - | Optional | |
| Tyres model | 8.25-16 | 8.25-16 | |
| Equipment | Heater | S | S |
| Adjustable steering wheel | S | S | |
| Power steering | S | S | |
| Exhaust brake | ○ | ○ | |
| Preheat | S | S | |
| Air deflector | - | - | |
| Air-conditioning | - | - | |
| Clutch booster | S | S | |
| Electric control window | ○ | ○ | |
| SABS | - | - | |
| Disc brake | - | - | |
| ABS | - | - | |
| S:Srandard ○:Under developed -:Undeveloped | |||
| Brand | T3 | T3 | T3 | |
| Basic Information | Cabin | Extended | ||
| Wheelbase(mm) | 3400 | 3600 | 3900 | |
| Overall demensionmm(mm) | 6150×2300×2740/2800 | 6490×2400×2815 | 6850×2500×2870 | |
| Cargo Inner Demension(mm) | 3900×2080×(800+200) | 4200×2200×1000 | 4520×2280×(800+400) | |
| Min.Ground clearance(mm) | 200 | 200 | 200 | |
| Rated payload(Kg) | 10000 | 10000 | 15000 | |
| GVW(Kg) | 15735 | 16355 | 22835 | |
| Max.speed(km/h) | 81 | 81 | 75 | |
|
Engine& Transmission |
Fuel Type | Diesel | Diesel | Diesel |
| Emission | EuroII | EuroII | EuroII | |
| Engine type | Weichai4105 | Yuchai4108 | Yuchai4110 | |
| Rated power(KW/rpm) | 95/2800 | 96/2800 | 105/2800 | |
| Max.torque(N.m/rpm) | 380/1600 | 380/1400~1700 | 430/(1300~1700) | |
| Steering system | Power assisted steering | Power assisted steering |
Power assisted steering |
|
| Transmission model | 5MT | 6MT | 4MT | |
| 548H | 653H | 885S | ||
| Brakes&Tyres | Service brake | Air brake | Air brake | Air brake |
| Parking brake | Air-cut brake | Air-cut brake | Air-cut brake | |
| Auxiliary brake | Exhaust Brake | Exhaust Brake | Exhaust Brake | |
| Tyres model | 8.25-20 | 9.00-20 | 10.00-20 | |
| Equipment | Heater | S | S | S |
| Adjustable steering wheel | S | S | S | |
| Power steering | S | S | S | |
| Exhaust brake | S | S | S | |
| Preheat | S | S | S | |
| Air deflector | - | - | - | |
| Air-conditioning | - | - | - | |
| Clutch booster | S | S | S | |
| Electric control window | ○ | ○ | ○ | |
| SABS | - | - | - | |
| Disc brake | - | - | - | |
| ABS | - | - | - | |
| S:Srandard ○:Under developed -:Undeveloped | ||||
