XCMG Working Weight 4000kgs Small Road Roller Model XMR403 , Vibration Road Roller
XCMG working weight 4000kgs road roller, model XMR403
Features:
Simple and flexible operation control, the electrical components to meet CE requirements, an increase of parking warning flashing lights to ensure the safety of people and equipment.
Frame with articulated frameless structure, making the width of the steel is greater than the width of the fuselage, to maximize the compaction of the curb near the homework.
Water tank capacity, can reduce downtime and water, improve work efficiency.
Specification:
| Model | XMR403 | |
| Engine | ||
| Model | ZN490B | |
| Rated power (kW) | 36 | |
| Rated speed (r/min) | 2600 | |
| Engine diesel consumption (g/kW·h) | 218 | |
| Working deta | Working deta | |
| Working weight (kg) | 4000 | |
| Front wheel static load weight (N/cm) | 157 | |
| Rear wheel static load weight (N/cm) | 157 | |
| Compress part | ||
| Vibration frequency (Hz) | 60 | |
| Rated amplitude (mm) | 0.41 | |
| Exciting force (kN) | 42 | |
| Drum diameter (mm) | 800 | |
| Drum width (mm) | 1300 | |
| Working deta | ||
| Driving speed(km/h) | 0～ 10.6 | |
| Gradeability (%) | 30 | |
| Min.turning radius (mm) | 3062/4362 | |
| Turning angle (°) | ±30 | |
| Swing angle (°) | ±10 | |
| Overall dimension | ||
| L (mm) | 2720 | |
| W (mm) | 1428 | |
| H (mm) | 2819 | |
| Min.ground clearance (mm) | 348 | |
|
The main products we deal with now are SINOTRUK HOWO, XCMG, SHANTUI, ZOOMLION and SANY. 1.dump trucks; cargo trucks Machine series: 1.Wheel loader,Backhoe loder, brick making machine 2.Roller, 3.Motor Grader, 4.Bulldozer, 5.Excavator, 6.Crane(truck crane,crawler crane,truck mounted crane,self erecting crane), 7,forklift and 45t contain reach stacker 8,paver and so on |
