New 375hp Beiben Truck Heavy Duty Dump Truck Front Lifting Manual Type Transmission
Product Description:
1.The vehicles adopts offset driving cabs with single door and single seat, used for mining.
2.The structure of metal framework and stressed-skin exclusive to the domestic heavy-duty trucks makes possible the security of European vehicles at the same level, and can satisfy the requirements of European ECER29 Security Regulations.
3.The vehicle frame is molded by stamping and this guarantees the strength of the crossbeams.
4.The axle technique unique of features such as high reliability, fuel economy, high attendance rate, strengthened structure, all making it suitable for the transportation of heavy goods , used as engineering machinery, under poor working condition such as in mine.
Special Features:
BEIEBN Dump truck:
Driving type:4x2,4x4 6x4,6x6,8x4,10x6
Engine: 266hp, 290hp, 300hp, 336hp,340hp, 350hp, 371hp, 375hp, 380hp
Engine power: EURO III, EURO IV.
Product list:
1. BEIBEN tippers: BEIBEN 4x2 tipper; BEIBEN 6x4 tipper; BEIBEN 8x4 tipper, BEIBEN 6x6 tipper, BEIBEN 10x6 tipper.
2. BEIBEN concrete mixers: BEIBEN 6x4 concrete mixers; BEIBEN 8x4 concrete mixers. Including 7m3, 8m3, 9m3, 10m3, 11m3 and 12m3.
3. BEIBEN tractors: BEIBEN 4x2 tractors; BEIBEN 6x4 tractors.
Engine power for the above heavy duty trucks is 266HP, 290HP, 336HP, 371HP and 420HP.
specification
| Product | Beiben 375HP 6x4 dump truck | |
| Chassis type | ND3250 | |
| loading capacity | 30-40Tons | |
|
Parameters |
Overall dimension L/W/H | 8450×2500×3450mm |
| Heavy body dimension L/W/H | 5600×2300×1600mm | |
| Volume of heavy body | 20m3 | |
| Thickness of heavy body side wall | 6mm | |
| Thickness of heavy body floor | 8mm | |
| Lifting system | Front lifting | |
| payload | 30000-40000 kg | |
| Curb Mass | 12400 kg | |
| Approach angle/ Departure angle | 26/32(°) | |
| Max Speed | 85 km/h | |
|
Engine |
Type | WP12.375 |
| Fuel Type | Diesel | |
| The max engine power | 375HP | |
| Displacement | 11596ml | |
| number of cylinders | 6 | |
| Exhaust emission standard | Euro 3 | |
| Manufacturer | Weichai Power Co.,Ltd | |
|
Transmission |
Transmission type |
Manual type,Fast brand, 12 Forward Gears 1 reverse gear |
| Transmission Manufacturer | Shaanxi Fast Gear Co.,Ltd | |
|
Cab |
Cab mode | All steel closed with air conditioning, one sleeper |
| Cab Lift method | Manual hydraulic turning system | |
|
Chassis |
Drive type | 6×4 |
| Wheelbase | 3800+1450 mm | |
| Suspension form | Leaf spring suspension system | |
| Tire Type and number | 12.00R20,10+1 spare tire,Radial tire | |
Other products:
Truck series:
1. Dump trucks; cargo trucks (1-120ton)
2. Tractor trucks; (1-120 tons)
3.Tanker trucks,( 54873020, 54798871, 54798867, 54633157, 54622108, 54621778, 54621524, water tanker and oil tanker)
4. Mixer trucks and concrete pump truck
5. Mine dump trucks( 30 tons off-road mine tipper, 50tons/70tons mine dump truck, 6x6 articualted dump trucks)
6. Off-road drive trucks( 4x4. 6x6 and 8x8 Trucks)
7. Garbage trucks( garbage compactor truck, suction trucks)
8. Truck mounted cranes(normal road truck crane, truck mounted crane)
9. Special trucks( wrecker trucks, military trucks...)
10.Semi trailers( container semi-trailer, low-bed semi-trailer, tanker trailer, dumper trailer...)
11.Truck spare parts
Machine series:
1.Wheel loader,Backhoe loader
2.Roller
3.Motor Grader
4.Bulldozer
5.Excavator
6.Crane(truck crane,crawler crane,truck mounted crane,self erecting crane)
7.Forklift and 45t contain reach stacker
8.Paver and so on
9. Spare parts
