6X4 Howo Dump Truck New Tipper Truck 336hp /371hp Engine Hw76 Cab
6X4 Howo Dump Truck New Tipper Truck 336hp /371hp Engine Hw76 Cab
Description:
A dump truck is a vehicle that unloads goods by itself by hydraulic or mechanical lift. Also called dump truck.
It is composed of automobile chassis, hydraulic lifting mechanism, cargo compartment and power take-off device.
The compartment of the dump truck is divided into two types: rearward tipping and sideward tipping, and the movement of the piston rod is controlled by the control system.
Front lift and rollover dump trucks, as well as two-way rollover dump trucks, are mainly used in construction projects.
Since the loading carriage can automatically tip over a certain angle for unloading, it greatly saves unloading time and labor, shortens the transportation cycle, improves production efficiency, and reduces transportation costs. It is a commonly used special-purpose vehicle for transportation.
Specification:
| Types of | Dump Truck |
| Rated quality | 12740 |
| total mass | 25000 |
| curb weight | 12130 |
| Fuel type | diesel fuel |
| number of axes | 3 |
| wheelbase | 3625+1350 |
| Axle load | 7000/18000 (two-axis group) |
| Number of tires | 10 |
| approaching the departure angle | 14/26 |
| front suspension rear suspension | 1500/1670,1500/1739 |
| Front track | 20,222,041 |
| rear track | 1830/1830 |
| vehicle length | 8145, 8214 |
| vehicle width | 2496, 2550 |
| vehicle height | 3450 |
| Cargo length | 5400, 5600 |
| Cargo width | 2300, 2350 |
| Cargo height | 950, 1195, 1500 |
| top speed | 82 |
| The number of occupants in the cab | 2 |
| Carrier Mass Utilization Coefficient | 1.06 |
HOWO 6X4 10 wheels dump truck middle tipping is mainly used for transporting the stuff in bulk which can be scattered (such as sand, soil, minerals, etc.), mainly in mining, construction sites and so on. The 10 wheels 6X4 dump truck with 25-30 tons capacity can meet your needs. All kinds of cargo body structure can be designed and produced according to your request, make it have light curb weight , high rigidity , high loading capacity.
