Fully Automatic White RO Water Purifying Machine 10 Ton for Water Process
Full automatic White 304 316ss RO water Purifying Machine 10 ton Water Process
Introduction of RO system
RO (Reverse Osmosis, RO), the basic working principle is: using of a special high pressure pump, increasing 6-20 kg pressure to raw water, then force raw water penetrating through 0.0001 micro reverse osmosis membrane under the pressure. Only water molecules and solvent less than 0.0001 microns can pass through the RO membrane. Chemical ionization, and bacterial, fungal, virus will flow with wastewater.
Features:
1. Automatic backwash and manual backwash
2. Automatic switch on when low water level, and switch off when high water level
3. Water shortage protection for multi-stage pump
4. Protection when no voltage, under-voltage, over-current, short circuit and creepage
5. Full stainless steel structure, durable and easy to clean.
6. Integrating water flow indicator, TDS indicator, pressure indicator, control panel
7. China Top Brand or world famous brand electrical, switch and valve systems
8. Built-in soft-start system to avoid damage to the expensive membrane when starting
9. Built-in RO membrane chemical washing device
10. PLC with touch-screen control available
| Parameters | |
| Product | Two-stage RO(Reverse Osmosis) water treatment machine |
| Model | RO-1000I(3000L/H) |
| Pure Water Production Capacity | 3000 litre per hour(25°C) |
| Input water quality | TDS≤2000PPM(SDI≤5, 2≤PH≥11, NTU≤1) |
| Minimum flux requirement for raw water(to reach the max output) | 6000L/H |
| Systematic Salt Rejection Rate | ≥98% |
| Recovery Rate(pure water : inlet water) | 50~75% |
| Recommended Working Temp. | 5~35°C |
| Input Power(standard) | AC380V / 50Hz / 8.10KW |
| Pre-treatment | |
| Quartz Sand Filter(Flux: 6M3/H) | Φ750×1500mm(t=2.0mm) SUS304 stainless tank with 800KG quartz sand Or optional fiber glass tank |
| Active Carbon Filter(Flux: 6M3/H) | Φ750×1500mm(t=2.0mm) SUS304 stainless tank with 300KG activated carbon optional fiber glass tank |
| Micron (PP Sediment) Filter | Φ330×500mm SUS304 stainless steel tank with 5u 20inch PP filter×8PCS |
| Booster Pump | China Nanfang CHL8-30 pump×1PC / 1.1KW |
| Multi-stage Pump for 1st stage RO | China Nanfang CDL4-220 pump×1PC / 4.0KW |
| Multi-stage Pump for 2nd stage RO | China Nanfang CDL4-220 pump×1PC / 3.0KW |
| Reverse Osmosis System | |
| Membrane | U.S. HYDRANAUTIC ultra-low pressure ESPA-4040 membrane × 18PCS Optinal DOW FILMTEC membrane |
| Housing | SUS304 stainless steel 40120 housing×6PCS |
| Accessories | |
| Piping | U-PVC quick connection |
| Structure | Full SUS304 stainless steel 40160 housing×2PCS |
| Electrical Parts | China Tengen |
| Others | Flow metre, TDS metre, pressure metre, electromagnetic valve, etc. |
| OPTIONAL | |
| Chemical dosing System for PH adjustment, anti-scaling, etc. | U.S. Pulsafeeder Xo60 Automatic Dosing valve with 50L tank |
