Automatic Tea Filling Machine Beverage / Chemical Bottle Filling Equipment
China well-known Tea filling/processing machine production line
Specifications
China well-known Tea filling/processing machine production line
1.tea filling machine
2.CE,ISO,SGS
3.tea processing machine
China well-known Tea filling/processing machine production line
This hot filling equipment adopts bottle neck holding transmission technology to realize fully automaic rinsing,filling and capping.It is equipped with perfect temperature control system,reverse-flow system,automatic cleaning system and control program.Each machine element that contacts with the liquid is made of high quality stainlesssteel and food-grade rubber.
1) Feature
China well-known Tea filling/processing machine production line
2) Technique parameter
| RCGF16-12-6 | RCGF18-18-6 | RCGF24-24-8 | |
| Productivity | 3000BPH | 6000BPH | 10000BPH |
| Rinsing Head | 16 | 18 | 24 |
| Filling Head | 12 | 18 | 24 |
| Capping Head | 6 | 6 | 8 |
| Bottle Volume | 350ml~2000ml±10ml | ||
| Bottle Diameter | φ50-92mm | ||
| Bottle Height | 150-310 mm | ||
| Filling Tolerance | ±2% | ||
| Cap Size | 28mm and 30mm PE Standard Caps | ||
| Air Pressure | 0.6MPa | ||
| Air Consumption | 500 L/min | ||
| Filling Water Consumption | 1.5 m3/h | 3 m3/h | 6 m3/h |
| Rinsing Water Consumption | 0.5 m3/h | 1 m3/h | 2 m3/h |
| Motor Power | 5.88kW | 6.68kW | 7.68kW |
| Voltage | 380V | ||
| Dimension |
(L*W*H) 2100*1500*2200mm |
(L×W×H) 2450*1800*2200mm | (L×W×H) 2750*2180*2200mm |
| Weight | 2500kg | 3000kg | 5300kg |
| Filling Principle | Gravity Filling | ||
Please kindly send us your requirements:
1, bottle vlolume
2, bottle materail (machines for glass bottle and plastic bottle are different)
3, how many bottlesper hour you want to produce ?
4, do you need this water filling machines only or whole water production line
We offer professional turnkey project from design till done of the whole project.
1.Project consultation
2.Design
3.Factory building
4.Installation
5.Commissioning
6.Training
We can provide beverage filling line as below:
1. Complete pure/mineral water production line
2. Complete pure/mineral water treatment machine
3. Complete juice production line
4. Complete carbonated beverage production line
5. 5 Gallons drinking water production line.
6.End-of-line packaging system
Our machine has been sold to more than 40 countries,almost of the customers are satisfiedwith the machines and our service.
We are a company integrating scientific research, production and service, and have the best manufacturing facilities and production process, professional staffs, imported facilities of concentration distill series, automatic CIP series, PLC control etc. Now we have been a market leader in the Chinese food machinery industry. The company keeps in mind the tenet of "serving users" and focus on research and development of new technologies. It has comprehensive development capacity and sound quality assurance system, and has made R&D achievement and obtained invention patents. Our machinery are widely sold in China, and exported over 20 countries, and gained favorable feedback from users. Our major engineering projects include complete dairy products production line, beverage production line, biochemical engineering production line.
