3 In 1 Water Bottle Filling Machine , Industrial Drinking Water Plant Machine
5L Bottle Drinking / Mineral Water Washing Filling Capping Machine
Description of 5L Drinking Water Washing Filling Capping Machine :
5L Water filling machine is used to fill pure water, mineral water and other non-carbonated beverage.
All the machine part which contact with liquid is high quality stainless steel 304. The relative fittings are
from international famous brand.
This machine is comprised of rinsing, filling and capping system. Rinsing: grip the bottle neck, rotate filling
plate, inverse bottle; internal rinsing and external spraying make bottles be cleaned completely. Filling:
gravity filling with holding bottle neck; the special backflow type of the filling valve can avoid leakage after
filling and also control liquid level accurately. Capping: magnetic torque bottle holding type can minimize
the cap damage rate and make the capping performance the best.
This machine owns the reasonable, stable and safe design. Under the condition that the bottle neck size
is the same, only the output star wheel needs to be changed if bottles are different. It improves the
efficiency a lot.
We are the water filling machine manufacturers in China.
Technical parameter
| Machine name | 5L bottled water production line mineral water processing machine / plant |
| Model | CGF9-9-4 |
| Filling speed | 1000BPH(5L) When the plastic bottle change from 3L to 10L, there's no need to change any spare parts in the monoblock filling machine |
| Rinsing head | 9 |
| Filling head | 9 |
| Capping head | 4 |
| Dimension | 3500mm*2500mm*2600mm |
| Weight | 4.5MT |
| Power | 7KW |
| Control system | Siemens PLC+touch screen |
| Electrical element | Schneider |
Customized service
1. We can design the machines according your requirements (materil ,power,filling type,bottles, and so
on),at the same time we will give you our professional suggestion,as you know,we have been in this
industry for many years.
2. We offer free technical support and consultation,such as draw the factory layout for you, alalyze the
source water report and so on.
If you want the detailed quotation including price,and the video of the machine or complet
line,please kindly leave me the following information!!!!!!!
1, bottle vlolume
2, bottle materail (machines for glass bottle and plastic bottle are different)
3, how many bottlesper hour you want to produce ?
4, do you need this water filling machines only or whole water production line
