Industrial Electric Water Bottle Filling Machine For Plastic / Glass Bottle
Factory Price 5L Bottle Pure Water Filling Machine / Bottling Line
CGF9-9-4
5L water bottle filling machine
The 5L bottle water filling machine is used for mineral water, pure water, drinking water filling and packing
in 3-10L PET bottle.
Monoblock means the filling machine integrates washing machine, filling machine and capping machine in
one frame. The driving system will be transmitted step by step which makes the speed more stable.
The monoblock filling machine will be made basing on:
1, the production capacity per hour
2, bottle type: plastic bottle, glass bottle or another
3, cap type: plastic screw cap, aluminum screw cap or another
Please send us the inquiry with above points so that we can help to send better quotation for reference.
Features
| Machine structure |
1. washing, filling and capping part in one unit; 2. one driving system makes the speed more stable 3. need one person to operate the machine 4. no noisy while running 5. more compact 6. different bottles can be applied in same machine (the bottle neck should be the same) |
| Washing part |
1. the star wheel to hold the bottle neck to avoid damage the bottle mouth 2. there is nylon grip to protect bottle mouth |
| Filling part |
1. round liquid tank, no residual after filling 2. the valves are stainless steel 304 3. no bottle no filling 4. filling level can be adjusted |
| Capping part |
1. there is anti-rotary blade to fix the bottle without moving 2. the capping torque can be adjusted |
| Control system |
1. PLC control 2. Touch screen |
| Electric part | All the electric parts are well-known brand |
Technical parameter
| Machine name | 5L bottled water production line mineral water processing machine / plant |
| Model | CGF9-9-4 |
| Filling speed | 1000BPH(5L) When the plastic bottle change from 3L to 10L, there's no need to change any spare parts in the monoblock filling machine |
| Rinsing head | 9 |
| Filling head | 9 |
| Capping head | 4 |
| Dimension | 3500mm*2500mm*2600mm |
| Weight | 4.5MT |
| Power | 7KW |
| Control system | Siemens PLC+touch screen |
| Electrical element | Schneider |
Our main products
1. bottling minereal/pure water production line (500ml, 1000ml,2000ml);
2. barrel mineral/ pure water production line (3L,5L,10L,19L,)
3. bottling carbonated beverage production line (like coca cola);
4. bottling juice production line;
5. canning beverage production line;
6. glass bottle beverage production line;
7. carbonated beverage and juice production auxiliary plants
