3000bph Monoblock Water Bottling Plant , Mineral Water Filling Machine
3000bph Monoblock Water Bottling Plant, Mineral Water
Plant Project Cost
Description
This machine is a monoblock one, it integrates rising filling and capping three functions in one unit, it can produce water 3000 bottles per hour, suitable for producing mineral water, pure water, spring water, vitamin water and juice beverage. it's an ideal plants for small scale production.
Technical parameter
| MODEL | CGF8-8-3 |
| Production Capacity | 2000-3000 bottles/h |
| Washing Head Quantity | 8 |
| Filling Valve Quantity | 8 |
| Capping Head Quantity | 3 |
| Filling Temperature | Normal temperature |
| Filling Type | Constant Pressure Filling |
| Main Motor Power | 3.42KW |
| Bottle diameter | 40-70mm |
| Bottle height | 130-260mm |
| Air resource pressure | 0.5Mpa |
| Filling Water | 1-1.5T/H |
| Consume Water | 0.8T/H |
| Control Type | PLC |
| Central Diameter of Filling Valve | ￠320mm |
| Central Diameter of Capping Machine | ￠120mm |
| Central Diameter of Washing Machine | ￠320mm |
| Dimension | 1850 X 1450X2000mm |
| Net Weight: | 2500kg |
characters
1. The mineral water filling machine adpots advanced human-machine interface control. High quality international name brand key components
2. Suspension bottle neck catcher structure allows the machine change the bottle type easily. By changing the valves, it also can be used as hot filling machine
3. High efficient air clean filter system ensures high sanitary requirements
4. Low overall machine noise
5. Self-lubricating system imported from America provides continuous smooth operation
Product pictures
inner look
filling heads
capping
Besides this 3000B/H, we also have other capacity
| Model | CGF 10-10-3 | CGF 18-18-6 | CGF 24-24-8 | CGF 32-32-10 | CGF 40-40-12 |
| Rinsing nozzles | 10 | 18 | 24 | 32 | 40 |
| Filling nozzles | 10 | 18 | 24 | 32 | 40 |
| Capping nozzles | 3 | 6 | 8 | 10 | 12 |
| Output(@500ml) | 4000BPH | 6000BPH | 8000BPH | 14000BPH | 18000BPH |
| Applicable bottle size | Diameter=50~108mm, H=170~340mm, 250~2000ml | ||||
| Pressure of air source | 0.7MPa | 0.7MPa | 0.7MPa | 0.7MPa | 0.7MPa |
| Air Consumption | 0.25M3/min | 0.8 | 0.8 | 0.8 | 0.8 |
| Pressure of spraying water | 0.2-0.25MPa | ||||
| Consumption of rinsing water | 1T/H | 1.2T/H | 1.2T/H | 2T/H | 2.2T/H |
| Pressure of filling | 0.2-0.3MPa | ||||
| Power consumption | 2.5kw | 3.5kw | 4kw | 5.5kw | 6.5kw |
| Machine body | SS304 | ||||
| Machine size(L*W*H,mm) | 2100*1800*2400 | 2300*2200*2400 | 3000*2200*2800 | 4000*2600*2800 | 4700*2900*2800 |
| Machine weight(kg) | 2500 | 3500 | 5500 | 6000 | 8000 |
If you want to get precise quotation, pls leave your capacity here,
more details i know more exact the proposal is... ...
