Commercial Fruit Juice Filling Machine , Hot Bottling Filling Equipment
Price:
pls inquiry
MOQ:
1 set
Delivery Time:
35 working days
Brand:
JIAYUAN
Product Description
Commercial Fruit Juice Making Machine, Fruit Juice Filling Line
Features
- It is applicable to different shaped bottles and plastic bottles: PP, PE, PVC, glass bottle and mould bottles.
- The bottle-in and bottle-out has specialized structure. It doesn't drop bottles or nip bottles.
- PLC control , simple and easy to operate.
- The part which touches the liquid medicine is made of 316L stainless material completely, meeting the requirement of GMP.
- It can be connected with the bottle-washing machine and the label-attaching machine to form a complete set of produce line.
- No bottle no filling. Unique drip proof device in production process, ensure no irrigation constant filling
- function.
- High filling accuracy
Technical parameter
| Model | RCGF32-32-10 |
| Capacity | 12000-15000bph (500ml PET bottle) |
| Suitable bottle | Polyester bottle, PET bottle |
| Filling materail | Fruit juice, tea, coffee, other non-carbonated beverage |
| Bottle Height | 150-310mm |
| Bottle Diameter | 40-108mm |
| Filling Temperature | ambient |
| Filling Technology | gravity filling |
| Applications | purified water and mineral water |
| Power supply | 380V 50Hz 3Phases or customized |
| Total power | 9.18KW |
| Dimension | 3600*2800*2200mm |
| Weight | 5500kg |
Product Details
final product
Besides this CGF32-32-10,we also have other capacity
| Model | RCGF16-12-6 | RCGF18-18-6 | RCGF24-24-8 | RCGF32-32-10 | RCGF40-40-12 | RCGF50-50-15 | |
| rising heads | 16 | 18 | 24 | 32 | 40 | 50 | |
| filling heads | 12 | 18 | 24 | 32 | 40 | 50 | |
| capping heads | 6 | 6 | 8 | 10 | 12 | 15 | |
| Bottle standard(mm) |
Diameter:Φ50-Φ108 Height:150-320 |
||||||
| Rated production capacity(B/H for 500ml) | 4000 | 6000 | 10000 | 12000 | 16000 | 24000 | |
| Installed capacity(KW) | 3.8 | 4.3 | 6.5 | 8.7 | 9.5 | 12 | |
| Overall size L*W*H(mm) | 3050*2000*2400 | 3170*2070*2400 | 4070*2350*2400 | 5100*2600*2400 | 6250*3050*2400 | 7500*3900*2400 | |
We smallest capcity is 2000B/H, waiting for you... ...
