6000B/H Capacity Glass Bottle Non-Carbonated Soft Drinks / Juice Monoblock Filler And Capper
Price:
pls inquiry
MOQ:
1 set
Delivery Time:
35 working days
Brand:
JIAYUAN
Product Description
6000B/H Glass Bottle Non-Carbonated Soft Drinks/Juice Monoblock Filler And Capper
Description
This machine is for glass bottle non carbonated beverage production. It's specially customized for our demestic customer, which can seal two different kinds caps in one machine, crown cap and ring-pull cap. It adopt normal pressure filling, suitable for producing various juice, tea, water and other non-carbonated beverage. The rough capacity is about 5000-6000 bottles per hour.
Parameter
| model | BCGF18-18-6-6 |
| Suitble bottle | Glass bottle |
| Suitable cap | Crown cap,ring-pull cap,aluminum screw cap |
| Filling material | Water, juice, tea, milk |
| Fillingi type | Normal pressure filling |
| Rising/filling/capping heads number | 18/18/6/6 |
| capacity | 6000B/H(for 500ml) |
| voltage | 380V 50Hz or customized |
| Material | SUS304 |
| Dimension | 2500*2000*2200mm |
| weight | 4000kg |
Pictures
rising
filling
crown cap sealing
ring-pull cap sealing
Our other products
| Model | BCGF16-12-6 | BCGF18-18-6 | BCGF24-24-8 | BCGF32-32-10 | BCGF40-40-12 | BCGF50-50-15 |
| Number of rising heads | 16 | 18 | 24 | 32 | 40 | 50 |
| Number of filling heads | 12 | 18 | 24 | 32 | 40 | 50 |
| Number of capping heads | 6 | 6 | 8 | 10 | 12 | 15 |
| Bottle standard(mm) |
Diameter:Φ50-Φ108 Height:150-320 |
|||||
| Rated production capacity(500ml) | 4000BPH | 6000BPH | 10000BPH | 12000BPH | 16000BPH | 24000BPH |
| Installed capacity(KW) | 3.8 | 4.3 | 6.5 | 8.7 | 9.5 | 12 |
