2RZ 2RS Ball Thrust Bearing
Quick Detail:
Brand Name: UMT
Bore Size: 70 mm
Outside Diameter: 125 mm
Model Number: 51314
Precision Rating: ABEC-1/ P0, ABEC-3/P6, ABEC-5/P5, ABEC-7/P4
Seals Type: open
Number of Row: Single Row
Place of Origin: Japan
Width: 40mm
Net weight: 2.000kg
Material: Chrome steel, Stainless steel
Cage: Steel, Brass, Nylon
Type: roller bearing
Clearance: C0, C1, C2, C3, C4, C5 etc.
Vibration: V1,V2,V3
Service: OEM Service & Good Service
Sample available: Yes
Manufacturer: Yes
Description:
Thrust ball bearing is a kind of separable bearing, they consist of a shaft washer, housing washer,
ball and cage assemblies, which can be mounted separately. Shaft washers have a ground bore to
enable an interference fit. The bore of the housing washer is turned and always larger than the shaft
washer bore.
Specifications:
|
51314 70*125*40mm thrust ball bearing |
|
|
Quality Standard: |
ISO9001:2008 quality management system, TS16949 |
|
Specification |
51314(Z1V1, P6) |
|
Brand Name: UMT ball bearing |
|
|
Size: 70*125*40mm |
|
|
Net weight: 2.000kg |
|
|
Seals Type: Z, ZZ, RS, 2RZ, 2RS |
|
|
Number of Row: Single Row ball bearing |
|
|
Material: Chrome steel, Stainless steel |
|
|
Dynamical load:133.20Kn |
|
|
Static load: 326.40Kn |
|
|
Cage: Brass, Steel, Nylon |
|
|
Features: |
1) Precision: ABEC-1(P0), ABEC-3(P6), ABEC-5(P5), ABEC-7(P4) |
|
2) Noise level: Z1, Z2, Z3, Z4 |
|
|
3) Vibration Level: V1, V2, V3, V4 |
|
|
4) Clearance: C2, C3, C4, C5 |
|
|
5) Hardness: 59-63 HRC |
|
and so on. |
|
|
Packing |
1. Industrial packing: plastic tube |
|
2. Commercial packing: small box then into standard carton |
|
|
3. As per customer's requirement |
|
|
Payment |
T/T, L/C, Western Union, MoneyGram, Paypal, D/A |
|
Delivery time |
About 2 to 7 working days after confirmed order |
|
Services |
Warranty time: 1 year |
|
Samples available: Yes |
|
|
Free technical support and after-sales service |
|
Applications:
mine machine, port hoisting machine, port oil transfer equipment, onshore and offshore crane; excavator,
concrete machine, paper machine, plastic and rubber machine, weave machine, steel plant, electronic
power plant, wind power generation, other construction and industry machines or equipment.
Competitive Advantage:
1. Quality level: reach the same level as the Japanese and European bearings
2. Tolerance level: ABEC-1 (P0), ABEC-3 (P6)
3. Less coefficient of friction
4. High limiting speed
5. Large size range
6. variations of structure
