Brass cage Angular Contact Ball Bearing 7311 BECBJ for winch dispersion machine

Brass cage Angular Contact Ball Bearing 7311 BECBJ for winch dispersion machine

Description:

Angular contact ball bearings are designed for combination radial and axial loading. Single-row bearings

have high thrust capacity in one direction. Some single-row bearings are specifically designed for duplex

mounting in sets for maximum performance. Double-row Conrad bearings can accommodate thrust in

both directions.

Applications:

Used in common applications, such as compressors, industrial transmissions, railway drive systems,

automotive drive systems.

Quick Detail:

1. Structure: Angular Contact

2. Type: Ball

3. Brand Name: UMT

4. Bore Size: 55mm

5. Outside Diameter: 120mm

6. Model Number: 7311 BECBJ

7. Precision Rating: P0,P6,P5,P4,P2

8. Seals Type: Z,ZZ,RS,2RZ,2RS

9. Number of Row: Single Row

10. Place of Origin: Japan

11. Width: 29mm

12. Net weight: 1.60kg

13. Material: Chrome steel, Stainless steel

14. Cage: Steel,Brass,Nylon

15. Type: ball

16. Clearance: C0,C1,C2,C3,C4,C5 etc.

17. Vibration: V1,V2,V3

18. Service: OEM Service & Good Service

19. Sample available: Yes

20. Manufacturer: Yes

Specifications:

Competitive Advantage:

1. Quality level: reach the same level as the Japanese and European bearings

2. Tolerance level: ABEC-1 (P0), ABEC-3 (P6)

3. Less coefficient of friction

4. High limiting speed

5. Large size range

6. variations of structure
