Agricultural Machinery NJ2205V Cylindrical roller bearing 25*52*18mm
Agricultural Machinery NJ2205V Cylindrical roller bearing 25*52*18mm
Description:
1. Seal form: open style, Z, ZZ, RS, 2RS, 2RZ
2. Bearing stop ring: N,NR
3. Class of precision: ABEC-1, ABEC-3, ABEC-5, ABEC-7
4. Vibration rank: V1, V2, V3, V4
5. Noise rank: Z1,Z2,Z3,Z4
6. Internal elimination code: C0, C2, C3, C4, C5
7. Bearing material: bearing steel (9Cr18), stainless steel(AISI440C, AISI304, AISI316), ceramics
Specifications
roller bearing nj2205v
1,Bearing steel material quality
2,Low noise and high precison,
3,long life
Products Details:
| P/N | NJ2205V Bearings |
| Brand | Koyo, NSK,Timken, FAG,EASE,IKO |
| Size | 25*52*18 mm |
| Precision | ABEC-1 |
| Type | Cam Followers |
| Lubrication | Grease |
| Material | Chrome Steel |
| Package | Plastic Bag and Box |
|
Name |
nj2205 Bearings |
|
Brand |
Koyo, NSK,Timken, FAG,EASE,IKO |
|
Precision |
P4, P5 |
|
Quality standard |
ISO9001:2000 standard |
|
Service |
OEM service |
|
Delivery date |
Normally ready goods and stock |
|
Payment terms |
|
|
Application |
automotive, rolling mill, mining, metallurgical, plastic machinery,etc. |
|
Package |
a. According to customer's requirements. |
| Bearing NO. | NJ2205V |
| Units | mm |
| Bearing Type | NJ |
| Bore Dia (d) | 25.0000 |
| Outer Dia (D) | 52.0000 |
| Width (B) | 18.0000 |
| Radius (min) (rs) | 1.000 |
| Dynamic Load Rating (Cr) | 34,600 |
| Static Load Rating (Cor) | 34,300 |
| Max Speed (Grease) | 11 |
| Max Speed (Oil) | 14 |
| Max. Shaft Shoulder Dia. Inner (Li) | 31.5 |
| Min. Housing Shoulder Dia., Outer (Lo) | 46.5 |
| Weight (g) | 166.00 |
| Precision | RBEC 1 |
| Standard Clearance | C0 |
| Material | 52100 Chrome steel, or equivalent |
Other Items:
Radial cylindrical roller bearings, due to a linear contact between the rings of the bearing and the rollers, offer a considerable amount of load. Also, this type is suitable for applications at high speed.
N2..,N3..,N32..,N33..,N34..,NJ22..,NJ23..,NU10..,NU2..,NU3..,NU4..,NU22..,NU23..,NUP2..,NUP22..,NUP23...,NUP3..,
Application:
Cylindrical roller bearings are available in many designs, series and sizes. The majority are single row bearings with a cage. High-capacity bearings, double row bearings, multi-row bearings, single, double and multi-row full complement bearings (without a cage) and split bearings complete the standard assortment provided here.
Packaging & Shipping:
| Package | Plastic Bag for bearings, and carton package outside | ||||||
| Shipping | Express,air shipment, and sea shipment are available | ||||||
| Service | OEM Service, and can print your onw logo after authorization |
||||||
