The Roof Panels made by our Roll Forming Machine have beautiful appearance and bright color. They are widely used in gardens, factories, resorts, hotels, exhibition halls, vacationlands, ancient architectures and modern villas.

• Decoiling the sheet
• Sheet guiding
• Roll forming
• Measure length
• Cutting the panel
• Panels to the supporter

5T Manual Decoiler - Used to support coil and enable rotary movement. Bearing capacity: 5T. Inner diameter: 470-530mm (adjustable). Equipped with brake device for impact protection.

Feeding Table & Pre-Cutter - Guides coil into correct position and includes hand pull cutting device for color or thickness changes.

Shaft & Roller - Made from 45# Steel Quenching and Plating. Processed rollers are smooth, hard, rust-resistant and won't scratch sheets.

Hydraulic Pump Station - Drives cutter for cutting operations. Uses 46# hydraulic oil with cooling fan for temperature control. Solenoid valve brand: Huade.

Touch Screen Control Cabinet - Features automatic and manual modes. Allows setting of sheet length and quantity. Electrical components: Delta VFD, Delixi circuit breakers and contactors, Xinling relays, Delta PLC, Delixi transformer.

Pressing Section & Cutter - Blade material CR12 with high strength, good hardenability and wear resistance.

Collects formed products with roller-equipped bracket to prevent scratching during forwarding.

This type of glazed tile has advantages including beautiful, classical appearance and graceful taste. It can be widely used in villages, hotels, exhibitions, vacation villages, family constructions and outdoor decoration.

Toppo Machinery Co., Ltd. is a professional supplier for roll forming machines. We provide an extensive line of products, including: roof and wall panel machines, tile roof machines, purlin forming machines, shutter door machines, floor decking machines and other associated equipment. Our roll forming machines are equipped with PLC control to ensure high accuracy and easy operation.
