Professional Automatic Metal Roof Glazed Tile Roll Forming Machine with 16 Stations, 4m/min Speed, and PLC Control
Professional supplier of automatic metal roof glazed tile roll forming machines with advanced manufacturing capabilities.
- Produces smooth, beautiful metal roofing sheets without surface scratches
- Complete rollforming process: uncoiler, rollforming, forming step effect, cut to length
- Fully Automatic Control System with PLC
- Easy operation: Set length and quantity via control panel
- One year comprehensive warranty
- Custom machine design available based on specifications and profile drawings
- One roll forming machine produces one specific profile
| Parameter | Specification |
|---|---|
| Material Type | PPGI/GI |
| Thickness | 0.3-0.6mm |
| Width | 1220mm |
| Roller Stations | 16 Stations |
| Roller & Shaft Material | 45# Steel Quenching and Plating |
| Diameter of Shaft | Φ70mm |
| Cutter Material | CR12 |
| Drive Type | Chain Drive |
| Speed | 4 m/min |
| Total Power | 5.5 + 5.5 KW |
| Voltage | 380V 50Hz 3 phases |
Supports steel coil and enables rotary movement (included free with machine)
- Coil inner diameter: 450-550mm
- Maximum coil width: 1250mm
- Maximum load capacity: 5T
Guides coil into correct position for roll forming with hand pull cutting device
45# Steel Quenching and Plating material ensures smooth, hard, rust-resistant rollers
Drives cutter for cutting operations with 46# hydraulic oil and cooling system
Features automatic/manual operation modes with Delta PLC and Delixi electrical components
Collects formed products with roller support system to prevent scratching
| Component | Quantity |
|---|---|
| Chains | 2 Sets |
| Solenoid Valve | 1 Set |
| Travel Switch | 2 Sets |
| Open-End Wrenches | 2 Sets |
| Hexagon Wrench | 2 Sets |
| Counter | 1 Set |
| Wrench | 2 Sets |
| Oil Seals | 1 Set |
Nude packaging with waterproof cloth and stow-wood. Control cabinet packed with waterproof cloth and box. Equipment guaranteed moisture-proof, anti-corrosive, and protected during transportation.
30% T/T deposit, remaining 70% T/T payment after buyer inspection at seller's factory before delivery.
30 working days after receipt of deposit.
Technician dispatch available to customer's country. Customer covers all costs including visa, round trip tickets, accommodation, and technician salary of USD 100-120 per day.
12-month comprehensive warranty. Replaceable parts provided free during warranty period (customer pays shipping). Includes operation CD and specifications in Chinese and English.
One complete equipment requires one 20-foot container.
